Description
DIMENSIONS
- Oven Dimensions (WxHxD)
- 30” x 37 1⁄16” x 27”
- Depth with Oven Door Open 90º (back of unit to front of the door open 90°) (IN)
- 46 7/32”
- Depth without Oven Door Handle (IN)
- 25
- Depth without Oven Door (IN)
- 24
- Range Size
- 30"
- Power Cord Length
- 4.27 (FT)
- Weight
- 150lbs
GENERAL INFORMATION
- LP Kit Provided
- Yes
- Work Support
- Yes
- Leveling Leg Max
- 1” - Min: 25⁄64
- Appliance type
- Gas Range
- Pressure Required (Inch WC)
- NG: Min. -4 / Max. 7
- LP: Min. -10 / Max. 11
DESIGN & FINISH
- Color
- Silver
- Finish
- Stainless Steel
- Handle Color
- Stainless Steel
- Knobs Color
- Stainless Steel
- Number of Knobs
- 6
- Case material
- Steel
- Case color
- Black Steel
TECHNICAL DETAILS
- LP Convertible
- Yes
- Electrical supply
- 120 V
- 60 HZ
- Dedicated Circuit Breaker
- 15 Amps
- Regulator Included
- Yes
- Pre-installed Regulator
- No
- Power cord Included
- Yes
- Power Cord Type
- NEMA 5-15P
COOKTOP FEATURES
- Simmer Burner
- Yes
- Cooktop surface type
- Cast Iron Grates/Black enamel
OVEN FEATURES
- Convection Type
- Single Fan
- Oven Cleaning Type
- Standard Clean
- Oven Lights
- 2
- Oven lights control switch activated
- Yes
- Temperature Range
- 140 0F - 500 0F
- Door Color
- Stainless Steel
- Oven interior color
- Black
WARRANTY & CERTIFICATIONS
- Certification
- cETLus
- Warranty
- 2 yrs
