Description
DIMENSIONS
- Overall Weight
- 592 lbs
- Overall Dimensions
- 60”W x 37.4”H x 28”D
- Cutout Dimensions
- 60.25”W x 28”D
- Right Oven Interior Dimensions
- 24.92”W x 16″H x 18.7”D
- Left Oven Interior Dimensions
- 24.92”W x 16″H x 18.7”D
- Power Cord Length
- 5′
GENERAL INFORMATION
- Title 20 – California Regulation
- Yes
- Switches
- 2 + 2
- Product Type
- Freestanding Range
- Supplier Intended and Approved Use
- Residential Use
- Country of Origin
- China
DESIGN & FINISH
- Color
- Silver
- Finish
- Stainless Steel
- Number of Knob
- 12
- Color/Finish
- Stainless Steel
- Gas Heat Configuration
- Sealed Burners
- Interior Light
- 2
- Control Type
- Knob
- Control Location
- Front
- Clock
- No
- Primary Material
- Metal
- Control Panel Material
- Stainless Steel
- Kick Plate Material
- Stainless Steel
- Side Panel Material
- Stainless Steel
TECHNICAL DETAILS
- Volts/Amperage
- 120V / 15A
- Receptacle Type
- 3-prong grounding-type
- Fuel Type
- Gas
- Gas Type
- Natural Gas
- LP Gas Convertible
- Yes
COOKTOP FEATURES
- Overall Burners BTU
- 142,000
- Front Right Burner BTU
- 1,000 to 20,000
- Front Right Center Burner BTU
- 15,000
- Front Center Burner BTU
- 15,000
- Front Left Center Burner BTU
- 15,000
- Front Left Burner BTU
- 20,000
- Rear Right Burner BTU
- 9,000
- Rear Right Center Burner BTU
- 15,000
- Front Center Burner BTU (2)
- 9,000
- Rear Left Center Burner BTU
- 15,000
- Rear Left Burner BTU
- 9,000
- Number of Burners
- 10
- Cooktop Surface
- Continuous Cast Iron Grates
- Cooktop Cavity
- Recessed Enamel
- Bake Element
- Gas
OVEN FEATURES
- Oven Door Open 90º
- 28”
- Overall Oven Capacity
- 8.64 Cubic Feet
- Overall Broil Top BTU
- 20,000
- Overall Bottom BTU
- 40,000
- Right Oven Capacity
- 4.32 Cubic Feet
- Right Broil Top BTU
- 10,000
- Right Bottom BTU
- 20,000
- Left Oven Capacity
- 4.32 Cubic Feet
- Left Broil Top BTU
- 10,000
- Left Bottom BTU
- 20,000
- Convection Fan
- Yes
- Number of Ovens
- 2
- Number of Racks
- 4
- Number of Rack Positions
- 2 x 6
- Broiler
- Gas
- Cleaning Type
- Manual
- Cooking Process
- Convection
- Temperature Gauge
- No
- Timer
- No
- Door Panel Material
- Stainless Steel
WARRANTY & CERTIFICATIONS
- ETL Listed
- Yes
