COOKTOP:
6 Dual Sealed Brass Burners
120,000 BTU Total Stove-Top Output
Deep Recessed Enamel
Heavy-Duty Continuous Cast Iron Grates
OVEN:
5.26 cubic feet capacity 36” Electric Oven
3 Telescopic Stainless-Steel Oven Racks
Blue Enamel Oven Interior
3-Layer Oven Door Glass
Halogen Oven Lights
U Tube Auto-Ignition
Convection Fan Hot Air Circulation
FEATURES:
Heavy-duty Food Grade 403 Stainless-Steel
Zinc Control Knobs
Red LED “Magic Eyes” Control Knob Illumination
Square Leg Covers
INCLUDES:
Complete Rotisserie Kit includes Skewer & Forks
Concave Wok Ring
LP Conversion Kit
Power Cord
|
Weight & Dimensions |
|
|
Overall Weight |
337.3 lb |
|
Overall Dimensions |
30” W x 37.4” H x 28” D |
|
Cutout Dimensions |
30.25” W x 28″ D |
|
Oven Door Open 90º |
+ 28″ |
|
Oven Interior Dimensions |
24.92” W x 16″ H x 18.7″ D |
|
Electrical |
|
|
Volts/Amperage |
240v/30A |
| Wattage | 3600w |
| Oven Broil Wattage inside | 1000w |
|
Oven Bake Wattage |
2000w |
| Oven Outside Wattage | 1800w |
| Convection Fan Wattage | 1500w |
| Power Cord Length | 3.9′ |
| Receptacle Type | 4-prong grounding-type |
|
Certifications |
ETL Listed |
|
Cooktop |
|
| Overall Burners BTU | 120,000 |
| Front Right Burner BTU | 20,000 |
| Front Center Burner BTU | 20,000 |
|
Front Left Burner BTU |
20,000 |
| Rear Right Burner BTU | 20,000 |
| Rear Center Burner BTU | 20,000 |
| Rear Left Burner BTU | 20,000 |
|
Oven |
|
| Overall Oven Capacity | 4.32 |
| Broil Top BTU | 10,000 |
| Bottom BTU | 20,000 |
| Convection Fan | Yes |
|
Other Specs |
|
|
Product Type
|
Freestanding Range
|
|
Color/Finish
|
Stainless Steel
|
|
Fuel Type
|
Gas & Electric
|
|
Gas Type
|
Natural Gas
|
| Gas Heat Configuration | Sealed Burners |
| Number of Burners | 6 |
| Cooktop Surface | Deep Recessed Enamel |
| Number of Ovens | 1 |
| Number of Racks | 3 |
| Broiler | Electric |
| Bake Element | Electric |
| Cleaning Type | Normal |
| Interior Light | 2 |
| Control Type | Knob |
| Control Location | Front |
| Sealed Burners | Yes |
| LP Gas Convertible | Yes |
| Convection Oven | Yes |
| Continuous Cast Iron Grate | Yes |
| Pro-Style Handle | Yes |
| Halogen Oven Lights | Yes |
| Adjustable Legs | Yes |
| Stainless Steel Square Leg Covers | Yes |
| Fingerprint Resistant | Yes |
| Soft Door Close | Yes |
| Illuminated Zinc Knobs | Yes |
| Blue Enamel Oven Interior | Yes |
| Food Grade 430 Stainless Steel | Yes |
| Back Splash Guard Included | Yes |
| Griddle Include | No |
| LP Conversion Kit Included | Yes |
| Thermostat | Yes |
| Regulator | Yes |
| Safety valves | Yes |
| Temperature Gauge | No |
| Timer | No |
|
Clock |
No |
| Primary Material | 304 Stainless Steel |
| Supplier Intended and Approved Use | Residential Use Only |
