Description
DIMENSIONS
- Product Dimensions
- 59 7/8” W x 29” D x 37 1/2” H
- Product Height (from bottom to top of back splash)
- 37 1/2”
- 39 1/2”
- Product Height (from bottom to top of side panel)
- 36”
- 38"
- Product Depth (From Back Panel To Handle)
- 29"
- Product Depth (from back panel to control board)
- 26 1/4" in.
- Product Depth (From Back Panel To Control Panel)
- 26 3/8”
- Product Depth (From Back Panel To Side Panel Front)
- 24"
- Cutout Dimensions (WxDxH)
- 60” x 24” x 36”
- Adjustable Leg Sizes
- 2" Max.
- Oven Internal Dimensions
- 23 3/4" W x 19 1/2” D x 18" H
- Net Weight
- 399 lbs
- Gross Weight
- 485 lb
- Power Cord Length
- 59"
GENERAL INFORMATION
- Convention
- Yes
- Baking Sheet Size
- 22” x 15” x 1 1/2”
DESIGN & FINISH
- Color
- Silver
- Finish
- Stainless Steel
- Control Type
- Oven Function and Temperature Knobs
TECHNICAL DETAILS
- Fuel Type
- Electric and Gas (NG / LP via Conversion Kit)
- Installation Type
- Built-In
- Electrical Requirements
- 120V
- Frequency(Hz)
- 60Hz
- Plug Type
- 3-Prong
COOKTOP FEATURES
- Total Burners
- 8
- [1] Front Left (Single
- 18,000 BTU
- [2] Front Right Center Burner (Single)
- 12,000 BTU
- [3] Front Right (Single)
- 18,000 BTU
- [4] Rear Right (Single
- 3,500 BTU
- [5] Rear Right Center Burner (Single)
- 12,000 BTU
- [6]Rear Left (Single)
- 12,000 BTU
- [7] Cast Iron Grill
- 9,000 BTU
- [8] Cast Iron Griddle
- 9,000 BTU
- Bake Burner Power
- 22,000 BTU + 22,000 BTU
- Broil Burner Power
- 13,500 BTU + 13,500 BTU
OVEN FEATURES
- Oven Capacity
- 4.8 + 4.8 cu. ft
- Cooking Modes
- Bake, Broil, Convection Bake,
- Convection Roast, Pizza, Keep Warm
- Oven Lights
- 40W (1 Left Oven, 1 Right Oven)
- Oven Racks
- 2 Left Oven, 2 Right Oven
- Oven Rack Materia
- Stainless Steel
- Air Fry
- No
- Sabbath Mode
- No
- Self Clean
- No
- Left Oven
- 2 Racks, 1 Broiler Pan
- Right Oven
- 2 Racks, 1 Broiler Pan
