Description
DIMENSIONS
- Product Dimensions (W x D x H)
- 34-5/16" x 22-1/2" x 12"
- Carton Dimensions (W x D x H)
- 38-3/16" x 16-59/64" x 28-47/64"
- Net Weight
- 54.5 lbs
- Gross Weight
- 68.5 lbs
GENERAL INFORMATION
- Brand
- Thor Kitchen
- Product
- 36 Inch Liner Hood
- Model Number
- XLH36
- Mount Type
- Insert
- Operating Mode
- Ducted
DESIGN & FINISH
- Color / Finish
- Stainless Steel
PERFORMANCE
- Max CFM
- 1200 CFM
- Blower Ratings (CFM / dBA)
- Min 350 / 48, Max 1200 / 70
- Number of Speed Settings
- 6
- Number of Lights
- 4
- Bulb Type
- LED (Square)
- Control
- Touch
- Filter Type
- Baffle Filter x 2
- Duct Diameter
- 10"
- Duct Shape
- Round
TECHNICAL DETAILS
- Voltage
- 120V
- Frequency
- 60Hz
- Amperage
- 7A
WARRANTY & CERTIFICATIONS
- Warranty
- 2 Years Parts and Labor
