Description
- Net Dimensions (In)
- 29.14 D x 32.875 H x 29.14 W
- Net Weight (Lbs)
- 206
- Gross Depth (In)
- 30.3
- Gross Height (In)
- 34.8
- Gross Width (In)
- 30.3
- Gross Weight (Lbs)
- 216
- Color
- Grey
- Inverter
- No
- SEER2
- 13.8
- EER2
- 11.2
- CFM
- 4000
- Tonnage
- 5
- Cooling Capacity (Btu)
- 55000
- Cycle
- 60
- Min Ambient Cool (F)
- 59
- Compressor Motor Type
- Scroll
- Condenser Fan Motor Type
- PSC
- Condenser Fan Motor Hp
- 1/3
- Decibel Rating (Dba)
- 65
- Voltage (V)
- 208/230
- Phase
- 1
- Max Fuse Breaker (A)
- 60
- Min Circuit Ampacity (A)
- 37
- Refrigerant Type
- R-454B
- Refrigerant Volume (Oz)
- 121.7
- Max Lineset Length (Ft)
- 150
- Liquid Line Size
- 3/8
- Suction Line Size
- 7/8
- Works With
- Signature Series Multi-Position or Stud Mount Air Handlers
- UL Listed
- Yes
- CSA Listed
- Yes
- ETL Listed
- Yes
- Energy Star Certified
- No
- AHRI Certified
- Yes
- Contains Electronics
- Yes
- Contains Chemicals
- Yes
- Contains Compressed Gas
- Yes
- Proposition 65 Warning
- Yes
- Base Warranty
- 10 Year Parts, Limited Lifetime Compressor Warranty
- Base Parts Warranty
- 10 Year
- Base Compressor Warranty
- Limited Lifetime
