Description
- Net Dimensions (In)
- 23.6 D x 25 H x 23.6 W
- Net Weight (Lbs)
- 144
- Gross Depth (In)
- 24.8
- Gross Height (In)
- 26.2
- Gross Width (In)
- 24.8
- Gross Weight (Lbs)
- 151
- Color
- Grey
- Inverter
- No
- SEER2
- 14.3
- EER2
- 11.7
- HSPF2
- 7.5
- CFM
- 1950
- Tonnage
- 2
- Cooling Capacity (Btu)
- 22000
- Heating Capacity (Btu)
- 22000
- Cycle
- 60
- Min Ambient Cool (F)
- 59
- Min Ambient Heat (F)
- 5
- Compressor Motor Type
- Scroll
- Condenser Fan Motor Type
- PSC
- Condenser Fan Motor Hp
- 1/9
- Decibel Rating (Dba)
- 60
- Voltage (V)
- 208/230
- Phase
- 1
- Max Fuse Breaker (A)
- 20
- Min Circuit Ampacity (A)
- 15.2
- Refrigerant Type
- R-454B
- Refrigerant Volume (Oz)
- 91.7
- Max Lineset Length (Ft)
- 100
- Liquid Line Size
- 3/8
- Suction Line Size
- 3/4
- Works With
- Signature Series Multi-Position or Stud Mount Air Handlers
- UL Listed
- Yes
- CSA Listed
- Yes
- ETL Listed
- Yes
- Energy Star Certified
- No
- AHRI Certified
- Yes
- Contains Electronics
- Yes
- Contains Chemicals
- Yes
- Contains Compressed Gas
- Yes
- Proposition 65 Warning
- Yes
- Base Warranty
- 10 Year Parts, Limited Lifetime Compressor Warranty
- Base Parts Warranty
- 10 Year
- Base Compressor Warranty
- Limited Lifetime
