Description
- Net Dimensions (In)
- 22.44 D x 9.65 H x 22.44 W
- Net Weight (Lbs)
- 35.27
- Gross Weight (Lbs)
- 41.89
- Mount Type
- Ceiling
- Color
- White
- Max Coverage Area
- Up to 400
- Air Flow Direction
- Downflow
- Number Of Speeds
- 5 (Variable)
- Oscillation
- Yes
- Tonnage
- 0.75
- Cycle
- 60
- Blower Motor Speeds
- 353.2/312/264.9/182.5/147.2
- Blower Motor Rpm
- 600/530/380
- Decibel Rating (Dba)
- 42.5/40/37.5/26/24
- Decibel Rating Low (Dba)
- 24
- Decibel Rating High (Dba)
- 42.5
- Voltage (V)
- 208/230
- Phase
- 1
- Max Fuse Breaker (A)
- 15
- Min Circuit Ampacity (A)
- 3
- Refrigerant Type
- R-454B
- Lineset Fitting Type
- Flare
- Liquid Line Size
- 4-Jan
- Suction Line Size
- 8-Mar
- Filter Type
- Reusable
- Auxiliary Heater Included
- No
- Auxiliary Heater Available
- No
- Fan Only Option
- Yes
- Sleep Mode
- Yes
- Auto Cool
- Yes
- Wifi Compatibility
- No
- App Compatibility
- No
- Works With Ios
- No
- Works With Android
- No
- Remote Control Included
- Yes
- UL Listed
- Yes
- CSA Listed
- Yes
- ETL Listed
- Yes
- Has Batteries
- Yes
- Contains Electronics
- Yes
- Contains Chemicals
- Yes
- Contains Compressed Gas
- Yes
- Proposition 65 Warning
- Yes
- Restricted States
- GU, PR, VI
- Base Warranty
- 5-Year Parts
- Base Parts Warranty
- 5-Year
- Base Remote Warranty
- 5 Year
- Registered Labor Warranty
- None
- Base Labor Warranty
- None
MRCOOL Mini Split BTU Guide
Drawn to scale — 1 square = 2 × 2 ft
