Description
- Net Width
- 17.5in
- Net Height
- 33.75in
- Net Depth
- 28.5in
- Net Weight
- 128 lbs
- Gross Width
- 20in
- Gross Height
- 41in
- Gross Depth
- 31.02in
- Gross Weight
- 155 lbs
- Fuel Type
- Natural/Propane Gas
- Stage
- Single
- Full Load
- 8A
- LP Kit Included
- Yes
- LP Kit Available
- Yes
- Cycle
- 60 Hz
- BTU Input
- 80,000 BTU
- BTU Output
- 64,000 BTU
- CFM
- 1,300
- Blower Motor Type
- ECM
- Blower Motor HP
- 1/2
- Blower Motor Speeds
- 5
- Blower Motor RPM
- 1,050
- Number of Speeds
- 5
- Voltage
- 115V
- Phase
- 1
- Max Fuse Breaker
- 15A
- Min Circuit Ampacity
- 8A
- Gas Connection Size
- 3/4in
- AFUE
- 80%
- Number of Burners
- 5
- Ignition Type
- Hot Surface
- Heat Exchanger Type
- Aluminized Tubular Steel
- UL Listed
- Yes
- ETL Listed
- Yes
- Contains Electronics
- Yes
- Proposition 65 Warning
- Yes
- Registered Parts Warranty
- 10 Years
- Base Parts Warranty
- 5 Years
- Registered Heat Exchanger Warranty
- Lifetime*
- Base Heat Exchanger Warranty
- 20 Years
