This product only includes a condenser. Click here for our complete central HVAC systems
Designed for consistent heating and cooling, the 5 Ton MRCOOL® VersaPro® Central Ducted Heat Pump Condenser provides comfort and efficiency throughout every season. This advanced 60k variable-speed unit features a SEER2 rating of 15.2 and an HSPF4 rating of 8.4, delivering reliable heating and cooling without excessive energy use. Paired with the MRCOOL® Central Ducted Air Handler, it forms a high-quality system tailored to your home’s specific needs. The DC inverter technology ensures smooth, quiet operation while helping to control utility costs, making it an ideal upgrade for older systems. With the included MRCOOL® Smart thermostat and wireless remote, you can adjust the temperature effortlessly, right at your fingertips.
The VersaPro® condenser also prioritizes sustainability with its use of eco-friendly R-454B refrigerant. Built to last, it features a durable painted galvanized steel construction and a compact side-discharge design that simplifies installation in smaller spaces. Maintenance is straightforward thanks to integrated self-diagnostics that help quickly identify issues. For added peace of mind, the 5 Ton MRCOOL® VersaPro® Central Ducted Heat Pump Condenser is backed by a 10-year warranty covering the compressor and parts. This ensures long-term reliability and protects your investment. Upgrade your HVAC system today and enjoy consistent, dependable comfort in every season.
Designed for consistent heating and cooling, the 5 Ton MRCOOL® VersaPro® Central Ducted Heat Pump Condenser provides comfort and efficiency throughout every season. This advanced 60k variable-speed unit features a SEER2 rating of 15.2 and an HSPF4 rating of 8.4, delivering reliable heating and cooling without excessive energy use. Paired with the MRCOOL® VersaPro® Central Ducted Air Handler, it forms a high-quality system tailored to your home’s specific needs. The DC inverter technology ensures smooth, quiet operation while helping to control utility costs, making it an ideal upgrade for older systems. With the included MRCOOL® Smart thermostat, you can adjust the temperature effortlessly, right at your fingertips.
The VersaPro® condenser also prioritizes sustainability with its use of eco-friendly R-454B refrigerant. Built to last, it features a durable painted galvanized steel construction and a compact side-discharge design that simplifies installation in smaller spaces. Maintenance is straightforward thanks to integrated self-diagnostics that help quickly identify issues. For added peace of mind, the 5 Ton MRCOOL® VersaPro® Central Ducted Heat Pump Condenser is backed by a 10-year warranty covering the compressor and parts. This ensures long-term reliability and protects your investment. Upgrade your HVAC system today and enjoy consistent, dependable comfort in every season.
|
Dimensions |
16.34" D x 38.39" H x 38.58" W |
|
SEER2 |
15.2 |
|
EER2 |
8.6 |
|
HSPF-4 |
8.4 |
|
HSPF-5 |
6.8 |
|
CFM |
3037.1 |
|
Tonnage |
5 |
|
Cooling Capacity (BTU) |
54000 |
|
Heating Capacity (BTU) |
54000 |
|
Voltage (V) |
208-230 |
|
Phase |
1 |
|
Cycle |
60 |
|
Max Fuse Breaker (A) |
40 |
|
Min Circuit Ampacity (A) |
39 |
|
Color |
gray |
|
Refrigerant Type |
R454B |
|
Refrigerant Volume (Oz) |
134.04 |
|
Decibel Rating (Dba) |
65 |
|
Liquid Line Size |
3/8 |
|
Suction Line Size |
3/4 |
|
WIFI Compatibility |
Yes |
|
APP Compatibility |
Yes |
|
ETL Certified |
Yes |
|
Energy Star Certified |
Yes |
|
AHRI Certified |
Yes |
|
Base Parts Warranty |
10 Years |
|
Base Compressor Warranty |
10 Years |
|
Contains Electronics |
Yes |
|
Contains Chemicals |
Yes |
|
Contains Compresed Gas |
Yes |
|
Gross Depth (In) |
19.68 |
|
Gross Height (In) |
42.52 |
|
Gross Width (In) |
45.08 |
|
Gross Weight (Lbs) |
224.21 |
*Shipping Policy
I ordered a HVAC system and it arrived in a timely manner and with no apparent issues. I thought the system was defective once installed but it was the installers fault who wired it wrong. My only issue would be the fee (30% I believe) to return a defective item within the 30 day return policy. If it is defective the customer shouldn't have to pay a fee to return an item that is not operating as designed. Other than that this is a good company.
Installed my own central HP system. It was a bit of work but nothing beyond a person with basic mechanical and electrical skills. It took me a while because I had to remove the existing electric forced air furnace from a pretty tight place. Some custom sheet metal work and a bit of custom electrical too. Worked perfectly when powered up and I actually like the thermostat provided, although I wish it was clearer how to set up a temperature set-back schedule. Pre-charged refrigerant piping was something new and I liked that too. The best thing is that my electric utility forked out $4,000 and that paid for the unit!
Installed with ceiling cassettes... Quiet and keeping us cool so far !
In the last few years I have installed four 12000 btu Mr Cool units and one of the 27000 btu units with two 12000 btu air handlers. I am happy with the performance of all of them, but if I had it to do over again, I would install two of the 12000 btu units instead of the 27000 btu unit. The price would be approximately the same, but the smaller units are much easier to deal with. The fact that the 12000 btu units require only 120 v power means that you can often make use of existing wiring rather than run a new line. The 27000 unit is quite heavy. It is much more difficult to move around . I didn't realize that fluid is pumped to both units even if only one of them is turned on. This results in confusing readings on the app and it probably results in reduced efficiency. I many cases using two smaller units rather than a large one would allow use of shorter lines. I appreciate that fact that HOD makes it easy to order units with appropriate line lengths rather than being forced to use standard sizes that may be longer than necessary.
Instead of waiting for my 18-year-old heat pump to stop operating in the middle of summer here in Florida, I decided to get the McCool 4 ton Versa before my old system got me. So, my Mr Cool arrived a few days after I ordered it and kept it in the garage until the weather cooled off since the Versa air handler was to be installed in the garage attic. However in the meantime, I ran the pressurized line set, purchased a few additional tools needed for the installation and hit the ground running when we got our first cool days. I took the old system offline by capturing the r22 freon in the old heat pump condenser, cut the lines and first installed with a little help, the Mr Cool outside condenser, the only thing that really required help. The attic air handler required me to pull the fan and the coil that lightened up the unit considerably, also allowing me to navigate it into the attic where I reinstalled both the fan and coil. Since the infrastructure was there from the old unit, it just required me to look up the existing AC and thermostat, mate the ductwork to the air handler and hook up the line set. I just followed the instructions and it all went very smoothly.
Finally, I hit the thermostat on switch and within a few minutes, had heat just in time for a 40° evening. Woke up to a cozy warm house for a change. Am very satisfied with my ducted Versa system and just in time because pulling apart the old system, it was very clear it wasn't going to make it another year or a week and feel great for saving thousands of dollars that I would have spent for a lesser system than this high-tech heat pump inverter system from MrCool.
