Description
- Net Dimensions (Inch)
- 46.44 D x 35.06 H x 50.69 W
- Net Weight (Lbs)
- 432
- Gross Depth (In)
- 48.625
- Gross Height (In)
- 37
- Gross Width (In)
- 51.44
- Gross Weight (Lbs)
- 458
- Fuel Type
- Natrual Gas / Propane
- Stage
- 1
- Color
- Grey
- Full Load
- 58
- Inverter
- No
- Metering Device
- Piston
- LP Kit Included
- Yes
- LP Kit Available
- Yes
- SEER2
- 13.4
- EER2
- 11
- CFM
- 930
- Tonnage
- 2.5
- Cooling Capacity (Btu)
- 28,400
- BTU Input
- 60000
- BTU Output
- 48000
- Cycle
- 60
- Min Ambient Cool (F)
- 64.4
- Compressor Motor Type
- Rotary
- Condenser Fan Motor Type
- PSC
- Condenser Fan Motor HP
- 1/6
- Condenser Fan Motor RPM
- 840
- Blower Motor Type
- ECM
- Blower Motor HP
- 1/2
- Blower Motor Speeds
- 4
- Decibel Rating (Dba)
- 79
- Voltage (V)
- 208/230
- Phase
- 1
- Max Fuse Breaker (A)
- 30
- Min Circuit Ampacity (A)
- 21.5
- Rated Load
- 13
- Refrigerant Type
- R-454B
- Refrigerant Volume (Oz)
- 44
- Gas Connection Size
- 1/2
- AFUE
- 81
- Number Of Burners
- 5
- Ignition Type
- Direct Spark Ignition
- Drain Connection Size
- 3/4
- Control Type
- 24V Thermostat
- UL Listed
- Yes
- CSA Listed
- Yes
- ETL Listed
- Yes
- AHRI Certified
- Yes
- Contains Electronics
- Yes
- Contains Chemicals
- Yes
- Contains Compressed Gas
- Yes
- Proposition 65 Warning
- Yes
- Registered Warranty
- 10 Year Parts, Lifetime Heat Exchanger
- Base Warranty
- 5 Year Parts, 20 Year Heat Exchanger
- Registered Parts Warranty
- 10 Year Parts
- Base Parts Warranty
- 5 Year Parts
- Registered Heat Exchanger Warranty
- Lifetime
- Base Heat Exchanger Warranty
- 20 Year
