Description
- Net Dimensions (Inch)
- 52 D x 24.81 H x 37.75 W
- Net Weight (Lbs)
- 326
- Gross Depth (In)
- 52.76
- Gross Height (In)
- 25.81
- Gross Width (In)
- 38
- Gross Weight (Lbs)
- 340
- Color
- Grey
- Full Load
- 55
- Inverter
- No
- Metering Device
- Piston
- SEER2
- 13.4
- EER2
- 11
- HSPF2-4
- 6.7
- CFM
- 840
- Tonnage
- 2
- Cooling Capacity (BTU)
- 22,800
- Heating Capacity (BTU)
- 22,400
- Cycle
- 60
- Min Ambient Cool (F)
- 32
- Min Ambient Heat (F)
- -0.4
- Compressor Motor Type
- Rotary
- Condenser Fan Motor Type
- ECM
- Condenser Fan Motor Hp
- 1/4
- Blower Motor Type
- PSC
- Blower Motor Hp
- 1/4
- Blower Motor Speeds
- 3
- Decibel Rating (Dba)
- 80
- Voltage (V)
- 208/230
- Phase
- 1
- Max Fuse Breaker (A)
- 25
- Min Circuit Ampacity (A)
- 17.9
- Rated Load
- 11.9
- Refrigerant Type
- R-454B
- Refrigerant Volume (Oz)
- 62
- Auxiliary Heater Included
- No
- Auxiliary Heater Available
- Yes
- Auxiliary Heater Sizes
- 5 KW
- 7.5 KW
- 10 KW
- Drain Connection Size
- 3/4
- Control Type
- 24V Thermostat
- Ul Listed
- Yes
- Csa Listed
- Yes
- Etl Listed
- Yes
- Ahri Certified
- Yes
- Contains Electronics
- Yes
- Contains Chemicals
- Yes
- Contains Compressed Gas
- Yes
- Proposition 65 Warning
- Yes
- Registered Warranty
- 10 Year Parts, 10 Year Compressor
- Base Warranty
- 5 Year Parts, 5 Year Compressor
- Registered Parts Warranty
- 10 Year Parts
- Base Parts Warranty
- 5 Year Parts
- Registered Compressor Warranty
- 10 Year Compressor
- Base Compressor Warranty
- 5 Year Compressor
