Experience superior heating and cooling along with reduced utility costs and less environmental impact with the MRCOOL® DC Inverter Package Heat Pump. Without relying on fossil fuels to heat or cool your home, this energy-efficient ducted system provides comfort in one conveniently packaged outdoor unit.
The variable speed DC compressor aids in the efficiency by generating less power loss, and since the motor doesn’t turn on and off regularly, the unit operates at a much lower noise level. This results in the room temperature being continuously regulated and adjusted to meet individual preferences.
The adjustable speeds of the compressor and DC motor create a wide range of cooling and heating operation between -22°F to 125°F. The unit offers a flexible air return from either the side or the bottom. This allows customers to install the system with a traditional installation method or on a rooftop. There are also optional heat kits available if needed.
Not only does the package unit quickly detect indoor and outdoor temperatures to adapt to load demands faster, but it is also equipped with intelligent defrosting technology that can judge frost conditions and improve heating performance during the winter.
Feel confident in your investment of the MRCOOL® DC Inverter Package Heat Pump thanks to its 10 year warranties on labor, parts, and the compressor–all of which require no tedious registration process.
| General Information | |
|---|---|
| SEER2 | 17.8 |
| EER2 | 11 |
| COP 47 | 11.6 |
| HSPF2 | 8.8 |
| Tonnage | 3 |
| Refrigerant Type | R410A |
| Refrigerant Volume | 176.4 oz |
| Voltage | 208-230V |
| Phase | 1 |
| Cycle | 60 Hz |
| Inverter | DC |
| ETL Listed | Yes |
| ETL Certified | Yes |
| Energy Star Certified | Yes |
| AHRI Certified | Yes |
| Performance | |
| Cooling Capacity | 34,400 BTU |
| Heating Capacity | 36,000 BTU |
| Max Fuse Breaker | 40A |
| Min Circuit Ampacity | 35A |
| Rated Load | 21.7A |
| Full Load | 2.7A |
| Decibel Rating | 63 dBA |
| Decibel Rating High | 73 dBA |
| Operating Range | |
| Min Ambient Cool | 23 ~ 125°F |
| Min Ambient Heat | -22 ~ 75.2°F |
| Compressor & Fan | |
| Compressor Motor Type | Inverter Rotary |
| Condenser Fan Motor Type | DC |
| Condenser Fan Motor HP | 0.5 |
| Condenser Fan Motor RPM | 920 |
| Filter | |
| Filter Type | Washable Aluminum |
| Filter Size | 28x9x3/5in |
| Features | |
| Auxiliary Heater Included | No |
| Auxiliary Heater Available | Yes |
| Low Voltage Compensation | Yes |
| Overload Protection | Yes |
| Adjustable Thermostat | Yes |
| WiFi Compatibility | No |
| Dimensions | |
| Net Width | 44in |
| Net Height | 49.25in |
| Net Depth | 35.43in |
| Net Weight | 523 lbs |
| Gross Width | 35.94in |
| Gross Height | 50.81in |
| Gross Depth | 44.63in |
| Gross Weight | 545 lbs |
| Warranty | |
| Base Parts Warranty | 10 Years |
| Base Compressor Warranty | 10 Years |
| Base Labor Warranty | 10 Years |
