MRCOOL Signature 80% AFUE, 45K BTU, 3 Ton, UpflowithHorizontal 5-Speed Gas Furnace - 14.5-Inch Cabinet (MGM80SE045A3A)

Click on image to zoom Click on image to zoom

MRCOOL Signature 80% AFUE, 45K BTU, 3 Ton, UpflowithHorizontal 5-Speed Gas Furnace - 14.5-Inch Cabinet (MGM80SE045A3A)

Name: MRCOOL Signature 80% AFUE, 45K BTU, 3 Ton, UpflowithHorizontal 5-Speed Gas Furnace - 14.5-Inch Cabinet (MGM80SE045A3A)
Brand: MRCOOL
SKU: MGM80SE045A3A
Price: 1191.0 USD
Availability: InStock
Rating: 4.8 (5 reviews)

| Authorized Dealer

SKU: MGM80SE045A3A

$1,191.00 $1,699.00

Save 30%

BTUs

45K 45K
70K 70K
90K 90K
135K 135K

Air Flow Position

Upflow/Horizontal Upflow/Horizontal
Downflow Downflow

Estimated delivery:

Secure Payment

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Free Shipping*
30-Day Return Policy⁺

MRCOOL Signature 80% AFUE, 45K BTU, 3 Ton, Upflow/Horizontal 5-Speed Gas Furnace - 14.5" Cabinet (MGM80SE045A3A)

80% AFUE 3 Ton 45,000 BTU Upflow/Horizontal 5-Speed Gas Furnace

When harsh winter weather strikes, nothing compares to the warmth and safety a powerful reliable gas furnace can provide. While furnace heating technology has been around for decades, not all systems are created equally. Some are definitely better than others. One of the best on the market is the MRCOOL single stage, 80% AFUE gas furnace.

This system can be installed upflow or horizontal, and is designed to operate for decades, provide powerful heating capability, and best of all, keep your heating bill affordable at the same time. It does the latter via its 80% AFUE energy efficiency rating. That mark of quality ensures 80% of every dollar you spend on heating fuel gets turned into real, effective heat for your home.

Features

Removable floor base for bottom return air
Easily removable slide out blower design Left or right utility connections
Zero step horizontal conversion
Aluminized steel inshot burners for smooth ignition
Multi-speed high efficiency (constant torque) blower motor
AHRI Certified
Aluminized steel tapered crimped non-welded clam shell heat exchanger design
Heating efficiency of 80% AFUE
Registered 10-year parts warranty
Compact 33" height
Rotatable draft inducer for venting flexibility

Dimensions	28 3/8" D x 33" H x 14 1/2" W
AFUE	80%
CFM	1230
Tonnage	3
Heating Capacity	44,000 BTU
Fuel Type	Natural Gas
BTU Input	44000
BTU Output	35200
Voltage	120
Phase	1
Cycle	60
Stage	Single
Max Fuse Breaker	15
Min Circuit Ampacity	6.8
Color	Gray
Color Family	Gray
Full Load	6.8
Number Of Speeds	5 Speed
Number Of Burners	4
GAS Connection Size	0.5
Blower Motor Type	ECM
Blower Motor HP	1/2
Blower Motor Speeds	5
Blower Motor RPM	535-1230
Heat Exchanger Type	Aluminized steel
Ignition Type	Silicon Nitride Ignitor
Vent Connector	4 inch
LP KIT Included	No
LP KIT Available	Yes
CSA Certified	Yes
ISO Certified	No
Energy Star Compliant	No
Energy Star Certified	No
AHRI Certified	Yes
Registered Warranty	Registered 10 Year Parts Warranty
Base Warranty	5 Year Parts Warranty
Registered Heat Exchanger Warranty	Registered 20 year Heat Exchanger Warranty
Base Heat Exchanger Warranty	20 year Heat Exchanger Warranty
Has Batteries	No
Contains Electronics	Yes
Contains Chemicals	No
Contains Aerosol	No
Contains Compressed GAS	No
Proposition 65 Warning	Yes
Restricted States	Yes (California)
Net Weight	111 lbs

What BTU rating should I choose for my air handler?

This depends on the coverage area/room size you are trying to heat/cool
An Air Handler's BTU is how powerful the fan is. A higher BTU rating will be able to heat/cool a larger area

Air Handler BTU	Coverage Area/Room Size (Sq Ft.)*
9K BTU	Up to 375 Sq. ft
12K BTU	Up to 500 Sq. ft
18K BTU	Up to 750 Sq. ft
24k BTU	Up to 1000 Sq. ft
36k BTU	Up to 1500 Sq. ft

*Ceiling height, insulation, and local climate may impact the coverage area. For example, an uninsulated room will require more power than a well insulated room.

*Shipping Policy

Shipping is Free
Large appliances ship via Freight Curbside shipment. Meaning the carrier will drop off your item on your property not inside your home. The courier company will call ahead of time to schedule a drop off date
For the full details, visit our Shipping Page

⁺Return/Refund Policy

30-Day Return Policy
If your order arrives damaged, we will exchange you for a new one. Damage must be reported within 24 hours.
For more details, visit our Return Policy Page

Nice unit

Very quiet operation, very heavy duty air handler, very poor installation instructions, but having 40+ years experience it wasn't too hard to figure out

It’s working

Just finished installing and can’t really give a review on efficiency or how effective the unit will be for my shop space. Installation was fairly straightforward, however, it would be beneficial that somewhere, prior to purchasing, incoming power will need to go the outside unit. I certainly would have planned running the #8 wire a little differently. I am satisfied with the purchase and excited to see the results in my shop.

Simple and straight forward.

Product came on time, well packaged and with no damage . I am a contractor and I have had many mini split systems installed in the past by subcontractors..Daikan, Fujitsu, Mitsubishi etc.. I decided to try the Mr Cool version my self since no vacuum work is needed. Overall the install was fairly simple and straight forward. If you live in snow country like me, make a note while material planning that there is no wall mounting brackets, snow stands or roof covering included. I ordered a set of wall brackets on Amazon for less than $50 which, so far have worked out well. I also grabbed an inexpensive set of brackets on Amazon for mounting an aluminium panel above the unit to act as a water/snow shed.
I was not sure what the instructions are speaking to regarding the needed air switch? After speaking with (2) master electricians, they were unsure as well so I did not install one. I did however install an overload circuit protector on the breaker feeding the exterior unit to protect the delicate circuit board of the system.
The only head scratcher I had throughout the install process was the size of the receiving connector terminals for the Line 1 and Line 2 at the exterior unit. They are the same sized terminals as the small communication wire terminal connections from the indoor units. It was more work than necessary (imo) to connect the heavy feed wire(s) that link the exterior unit from the breaker. We got it connected, but I'm not sure why these terminals aren't designed larger?
I ordered longer length line sets than I measured and glad I did as there really wasn't a lot of slack left in the line sets when my wall units were all completed and installed. A good rule of thumb is more is better than less. One bit of advice I would give is find out how many ports your unit has for the option of future interior wall unit additions. In my case, I ordered a 27K BTU exterior condenser which had (3) ports. Included with my purchase kit was (2) interior units. Had I thought better of it, I would have attempted to order an upsized exterior unit for the potential to add another interior unit in my garage in the future, but my exterior unit only has 6K BTU's of unused capacity which is really not enough for my garage. I'll be ordering a separate unit for that in the future. I also plan to purchase another (2) systems to outfit the remainder of our two story colonial. Overall very pleased.

Mr.Cool multizone install.

I have not completed the install yet and so this review will not be complete. So far all is going well. There are a few issues however. The first is that I was informed a wall mount bracket for the outside condenser unit would come with the order. It did not. This slowed the install as I had to wait for a bracket to come in. Next, the filler putty for the line set hole was nowhere near enough to fill the hole correctly. I would say at least double the amount sent would be needed to properly fill the gap for sealing. So far, other than these issues the install is going well. If you send me another review after the install I will give more info. As a last note I would say that I was disappointed in the exterior line set cover kit. It only comes in 12 foot lengths and all of my line sets are 16 feet. These kits are rather expensive and I did not want to buy 2 for every line set, and I have 3 line sets. That gets pretty pricey and it is a shame you don't sell line set kits for the different lengths of line set you sell. Thank you.

Great

great
