Installation of any product must comply with all applicable codes and regulations. The service of a certified and trained electrical technician may be required for the installation process.
Dimensions | 58.5" H x 32" L x 25.75" W |
---|---|
Model | GCHPD048TGTANDL |
AHRI Number | 204346874 |
Air Flow Direction | Downflow |
Avg Coverage Area | 2,000 - 2,400 Sq Ft |
Blower Motor | Variable Speed |
Compressor | Two Stage |
Cooling Capacity | 4 Ton |
EER | 33 |
Electrical Phase | 1-Phase |
Heat Pump Efficiency (COP) | 5.0 |
HWG Connection | 1/2 inch |
Loop Connection | 1 inch |
Max Overcurrent Protection | 60 amps |
Primary Heating Capacity | 45,001 - 50,000 BTU |
Voltage | 240 |
Warranty | 5 Year |
Weight (lbs) | 345.00 |
California Residents | See Prop 65 WARNING |
What BTU rating should I choose for my air handler?
Air Handler BTU | Coverage Area/Room Size (Sq Ft.)* |
9K BTU | Up to 375 Sq. ft |
12K BTU | Up to 500 Sq. ft |
18K BTU | Up to 750 Sq. ft |
24k BTU | Up to 1000 Sq. ft |
36k BTU | Up to 1500 Sq. ft |
*Ceiling height, insulation, and local climate may impact the coverage area. For example, an uninsulated room will require more power than a well insulated room.
