Description
- Indoor Unit Dimensions
- 31.57 W" x 7.87 D" x 11.61 H"
- Outdoor Unit Dimensions
- 28.35 W" x 10.63 D" x 19.49 H"
- Indoor Unit Net Weight
- 24.91 lbs
- Indoor Unit Gross Weight
- 35.71 lbs
- Outdoor Unit Net Weight
- 54.89 lbs
- Outdoor Unit Gross Weight
- 67.24 lbs
- Indoor Packing Dimensions
- 36.02 W" x 17.95 D" x 14.17 H"
- Outdoor Packing Dimensions
- 32.87 W" x 10.63 D" x 21.26 H"
- Series
- MRCOOL DIY Easy Pro
- Indoor Unit Model
- EZPRO-12-HP-WMAH-115DE-O
- Outdoor Unit Model
- EZPRO-12-HP-C-11511DE-O
- System Type
- Single-Zone Ductless Mini-Split Heat Pump
- Mount Type
- Wall
- Color
- White
- Configuration
- DIY Pre-Charged Quick Connect
- Fan-Only Mode
- Yes
- Auto Restart
- Yes
- Active Clean Technology
- Yes
- Condenser Coil
- Gold Fin® Corrosion-Resistant
- Tonnage
- 1
- Cooling Capacity
- 12,000 Btu/h
- Heating Capacity
- 12,000 Btu/h
- SEER2
- 19.5
- EER2
- 9
- HSPF2-4
- 9.3
- HSPF2-5
- 7
- Max Coverage Area
- Up to 550 sq. ft.
- Operating Temperature Range
- -13°F to 122°F
- Min Ambient Cooling
- 5°F
- Inverter
- DC Inverter
- Low Ambient Cooling
- Down to 5°F
- Compressor Type
- Rotary
- Number of Fan Speeds
- 5
- Indoor Noise Level (Turbo/Hi/Mid/Lo/Silent)
- 44.5 / 40 / 35 / 25.5 / 17.5 dB(A)
- Outdoor Noise Level
- 54 dB(A)
- Power Supply
- 115V, 1Ph, 60Hz
- Indoor Min Circuit Ampacity
- 3.0 A
- Indoor Max Fuse (Breaker)
- 15.0 A
- Outdoor Min Circuit Ampacity
- 19.5 A
- Outdoor Max Fuse (Breaker)
- 20.0 A
- Refrigerant Type
- R-454B
- Refrigerant Charge
- 21.52 oz
- Liquid Line Size
- 1/4"
- Gas (Suction) Line Size
- 3/8"
- Included Line Set Length
- 11.5 ft (Pre-Charged Quick Connect®)
- Max Line Set Length
- 82 ft
- Refrigerant Leakage Detection
- Yes
- Filter Type
- Reusable / Washable
- WiFi Compatibility
- Yes
- App Compatibility
- MRCOOL Comfort App
- Works with iOS
- Yes
- Works with Android
- Yes
- Amazon Alexa
- Yes
- Google Assistant
- Yes
- Remote Control Included
- Yes
- Follow Me® Function
- Yes
- Sleep Mode
- Yes
- Auto Cool
- Yes
- Timer Mode
- Yes
- UL Listed
- Yes
- CSA Listed
- Yes
- ETL Listed
- Yes
- AHRI Certified
- Yes
- NEEP ccASHP Listed
- Yes
- CEE Tier 1 - North
- Yes
- Energy Star Certified
- Yes
- Compressor Warranty
- 5 Years (with online registration)
- Parts Warranty
- 3 Years (with online registration)
