MRCOOL Signature 80% AFUE, 90K BTU, 5 Ton, Upflow/Horizontal 5-Speed Gas Furnace - 21" Cabinet (MGM80SE090C5A)

80% AFUE 5 Ton 90,000 BTU Upflow/Horizontal 5-Speed Gas Furnace



When harsh winter weather strikes, nothing compares to the warmth and safety a powerful reliable gas furnace can provide. While furnace heating technology has been around for decades, not all systems are created equally. Some are definitely better than others. One of the best on the market is the MRCOOL single stage, 80% AFUE gas furnace. This system can be installed upflow or horizontal, and is designed to operate for decades, provide powerful heating capability, and best of all, keep your heating bill affordable at the same time. It does the latter via its 80% AFUE energy efficiency rating. That mark of quality ensures 80% of every dollar you spend on heating fuel gets turned into real, effective heat for your home.



Features

  • Removable floor base for bottom return air
  • Easily removable slide out blower design
  • Left or right utility connections
  • Zero step horizontal conversion
  • Aluminized steel inshot burners for smooth ignition
  • Multi-speed high efficiency (constant torque) blower motor
  • AHRI Certified Aluminized steel tapered crimped non-welded clam shell heat exchanger design
  • Heating efficiency of 80% AFUE
  • Registered 10-year parts warranty
  • Compact 33" height
  • Rotatable draft inducer for venting flexibility

Dimensions

28 3/8" D x 33" H x 21" W

AFUE

80%

CFM

2060

Tonnage

5

Heating Capacity

88,000 BTU

Fuel Type

Natural Gas

BTU Input

88000

BTU Output

70400

Voltage

120

Phase

1

Cycle

60

Stage

Single

Max Fuse Breaker

15

Min Circuit Ampacity

10.9

Color

Gray

Color Family

Gray

Full Load

10.9

Number Of Speeds

5 Speed

Number Of Burners

8

GAS Connection Size

0.5

Blower Motor Type

ECM

Blower Motor HP

1

Blower Motor Speeds

5

Blower Motor RPM

1200-2060

Heat Exchanger Type

Aluminized steel

Ignition Type

Silicon Nitride Ignitor

Vent Connector

4 inch

LP KIT Included

No

LP KIT Available

Yes

CSA Certified

Yes

ISO Certified

No

Energy Star Compliant

No

Energy Star Certified

No

AHRI Certified

Yes

Registered Warranty

Registered 10 Year Parts Warranty

Base Warranty

5 Year Parts Warranty

Registered Heat Exchanger Warranty

Registered 20 year Heat Exchanger Warranty

Base Heat Exchanger Warranty

20 year Heat Exchanger Warranty

Has Batteries

No

Contains Electronics

Yes

Contains Chemicals

No

Contains Aerosol

No

Contains Compressed GAS

No

Proposition 65 Warning

Yes

Restricted States

Yes (California)


Mini Split FAQ

What BTU rating should I choose for my air handler?

  • This depends on the coverage area/room size you are trying to heat/cool
  • An Air Handler's BTU is how powerful the fan is. A higher BTU rating will be able to heat/cool a larger area
Air Handler BTU Coverage Area/Room Size (Sq Ft.)*
9K BTU
Up to 375 Sq. ft
12K BTU Up to 500 Sq. ft
18K BTU Up to 750 Sq. ft
24k BTU Up to 1000 Sq. ft
36k BTU  Up to 1500 Sq. ft

*Ceiling height, insulation, and local climate may impact the coverage area. For example, an uninsulated room will require more power than a well insulated room.
