MRCOOL Signature 5 Ton, Variable Speed Modular Blower - Multi-Position (MMBV20DE)

MRCOOL Signature 5 Ton, Variable Speed Modular Blower - Multi-Position (MMBV20DE)

SKU: MMBV20DE

Sale price$952.00 Regular price$1,499.00
Save 36%



Estimated delivery:
  • Secure Payment
    Amazon American Express Apple Pay Diners Club Discover Google Pay Mastercard PayPal Shop Pay Venmo Visa
    Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
  • Free Shipping*
  • 30-Day Return Policy⁺

Description

MRCOOL Signature 5 Ton, Variable Speed Modular Blower - Multi-Position (MMBV20DE)

5 Ton Multi-Positional Variable Speed Modular Blower



The MRCOOL Multi-Position Modular Blower is designed to deliver dependable comfort, and is built for reliability. The electronically commutated motor (ECM) delivers consistent airflow throughout the seasons, allowing you to remain relaxed at all times. When choosing a MRCOOL Multi-Position Modular Blower, you can always know that you are being energy and time efficient.



Features

  • Cabinet dimensions match standard furnace widths
  • Painted galvanized cabinet
  • ECM variable speed motors
  • Field installed 5-20 kW heat strips
  • Factory installed fan relays for non-heat strip installations
  • 10 year limited parts warranty
  • ETL and ETLC approved
  • AHRI certified
  • Variable speed blower motor
  • Upflow, counterflow, and horizontal configurations
  • Approved for installation in manufactured housing and mobile homes
  • Made in the USA

Dimensions

24.5" D x 26" H x 21" W

CFM

1780

Tonnage

5

Cooling Capacity

560-1780

Voltage

208-230

Phase

1

Cycle

60

Max Fuse Breaker

15

Min Circuit Ampacity

0

Color

Gray

Color Family

Gray

Max Coverage Area

2500

Refrigerant Type

R-410A

Number Of Speeds

Variable

Inverter

No

Blower Motor Type

ECM

Blower Motor HP

3/4

Blower Motor Speeds

Variable Speed

Filter Type

Replaceable

Filter Size

20x30(2)

Auxiliary Heater Sizes

15kw

UL Reconized

No

UL Listed

No

ETL Listed

Yes

ETL Certified

No

ISO Certified

No

LEED Certified

No

Energy Star Compliant

No

Energy Star Certified

No

AHRI Certified

Yes

Registered Warranty

10 Year Limited Parts Warranty

REGISTERED PARTS WARRANTY

10 Year Limited Parts Warranty

Has Batteries

No

Contains Electronics

Yes

Contains Chemicals

Yes

Contains Aerosol

Yes

Contains Compressed GAS

Yes

Proposition 65 Warning

Yes

Restricted States

No

Net Weight

105

Gross Depth

26.5

Gross Height

28

Gross Width

24

Gross Weight

105


Mini Split FAQ

What BTU rating should I choose for my air handler?

  • This depends on the coverage area/room size you are trying to heat/cool
  • An Air Handler's BTU is how powerful the fan is. A higher BTU rating will be able to heat/cool a larger area
Air Handler BTU Coverage Area/Room Size (Sq Ft.)*
9K BTU
Up to 375 Sq. ft
12K BTU Up to 500 Sq. ft
18K BTU Up to 750 Sq. ft
24k BTU Up to 1000 Sq. ft
36k BTU  Up to 1500 Sq. ft

*Ceiling height, insulation, and local climate may impact the coverage area. For example, an uninsulated room will require more power than a well insulated room.

Shipping & Returns

*Shipping Policy

  • Shipping is Free
  • Large appliances ship via Freight Curbside shipment. Meaning the carrier will drop off your item on your property not inside your home. The courier company will call ahead of time to schedule a drop off date
  • For the full details, visit our Shipping Page

Return/Refund Policy
  • 30-Day Return Policy
  • If your order arrives damaged, we will exchange you for a new one. Damage must be reported within 24 hours.
  • For more details, visit our Return Policy Page



Customer Reviews

Based on 23 reviews
96%
(22)
4%
(1)
0%
(0)
0%
(0)
0%
(0)
P
Peter K. (Phoenix, US)
Pretty Easy Install and Works Great!

Installed my own central HP system. It was a bit of work but nothing beyond a person with basic mechanical and electrical skills. It took me a while because I had to remove the existing electric forced air furnace from a pretty tight place. Some custom sheet metal work and a bit of custom electrical too. Worked perfectly when powered up and I actually like the thermostat provided, although I wish it was clearer how to set up a temperature set-back schedule. Pre-charged refrigerant piping was something new and I liked that too. The best thing is that my electric utility forked out $4,000 and that paid for the unit!

W
WesD (Chicago, US)
Installed and working great

Installed with ceiling cassettes... Quiet and keeping us cool so far !

N
Nat R. (Odessa, US)
4 ton condensing unit

Very good delivery service installed and works like a Should

w
walter w. (Port Neches, US)
Old r22 unit, same capacity, worked better in temperature extremes

Product came packaged well, undamaged. Installation was difficult, followed instructions for suction line above coil on bilevel installation with coil above condenser. 108 inside house on startup, 103 ambient. First start, high pressure 500, low pressure 170, supply air temp 66 degrees. Very worried at first, but after house cooed down, everything within parameters. Researched 410a refrigerant, found out it looses efficiency exponentially during temperature extremes. My old r22 unit would supply 54 degree supply air in comparable operating conditions. EPA, government, a/c manufactures all lying to American public

j
justin N. (New York, US)
Well built

First time ever installing Mr cool unit was built very good it has a dc converted fan motor,came with a salt shelf type coating om inside of unit over all very impressed 5star system
