PioneerSKU: PYM012GZUI16RD
3 reviews
Price:
$1,798.00 $2,569.00SAVE 30%
In Stock
Estimated delivery: Sep 21st-28th
Free Curbside Delivery — carrier calls to schedule

Free Curbside Delivery

Included on every order
Ships free by freight carrier. Your order leaves the warehouse tracked, on a palletized freight truck.
The carrier calls ahead. You'll schedule a delivery window that works for you before the truck heads out.
Delivered to the curb. The item is placed at the end of your driveway. Moving it inside is your responsibility, so plan to have help on hand for heavy pieces.
Before you sign: inspect the packaging for damage. Signing the delivery receipt confirms it arrived in good condition.

Description

Summary

  • Inverter-Driven Pioneer® All-In-One Packaged Console Heat Pump System
  • Cooling capacity: 11,800 BTU/H with 15.55 SEER2 efficiency
  • Heating capacity: 10,900 BTU/H with 8.15 HSPF2 efficiency
  • Electric Heat capacity: 10,236 BTU/H
  • Voltage: 208/230V, 60Hz, 1Ph
  • Factory-Precharged with Environmentally Friendly R-32 Refrigerant
  • Monoblock-style design with no outdoor unit required

Features

  • Heat Pump with Cooling, Heating, Dry, Auto and Fan Modes
  • Washable, Reusable Air Filters
  • Dual-Axis Airflow (Motorized Up-Down and Left-Right Louvers)
  • Treated Airflow of 265 CFM with optional 18 CFM of Fresh-Air
  • Functional Remote with:
    • SLEEP Mode, for Energy-Conservation
    • Timer On/Off Control

Technical Information & Performance

  • Power Supply: 208~230V, 60Hz, 1Ph
  • Cooling Rated Capacity: 11,800 BTU/h
  • Heating Rated Capacity: 10,900 BTU/h
  • Electric Heat Rated Capacity: 10,236 BTU/h
  • Refrigerant Type: R-32
  • Refrigerant Charge: 22.9 oz (650 g)
  • Rated Power (Cooling): 1,209 W
  • Rated Power (Heating): 947 W
  • Rated Power (Electric Heater): 3,000 W
  • Rated Current (Cooling): 6.1 A
  • Rated Current (Heating): 4.8 A
  • Rated Current (Electric Heater): 13.6 A
  • Required Circuit Amperage: 20A (double-pole)
  • SEER2: 15.55 BTU/W.h
  • HSPF2: 8.15 BTU/W.h
  • Airflow: 330 CFM
  • Sound Level: 48 / 45 / 42 dB(A)
  • Air Moisture Removal Capacity: 1 Liter/hour
  • Temperature Setting Range (Remote Control): 64-86°F (18-30°C)
  • Cooling Mode Operating Range (Indoor): 63-90°F (17-32°C)
  • Cooling Mode Operating Range (Outdoor): 63-109°F (17-43°C)
  • Heating Mode Operating Range (Indoor): 28-81°F (-2-27°C)
  • Heat Pump Heating Mode Operating Range (Outdoor): 28-75°F (-2-24°C)
  • Dimensions (WDH): 39"-1/2 x 7"-5/8 x 22"-3/4 Inches
  • Weight: 117.0 lbs (53.1 kg)
DIMENSIONS
Product Dimensions
39.5" W x 7.63" D x 22.75" H
Product Weight
117 lbs (53.1 kg)
GENERAL INFORMATION
Type
Through-the-Wall Monoblock Heat Pump
Installation Type
Through-the-Wall (no outdoor unit)
Compressor
Inverter-driven
Refrigerant
R-32 (factory precharged, 22.9 oz)
PERFORMANCE
Cooling Capacity
11,800 BTU/h
Heating Capacity (Heat Pump)
10,900 BTU/h
Electric Heat Capacity
10,236 BTU/h
SEER2
15.55
HSPF2
8.15
Airflow
330 CFM (265 CFM treated air + optional 18 CFM fresh air)
Moisture Removal
1 liter/hour
Sound Level
48 / 45 / 42 dB(A)
TECHNICAL DETAILS
Power Supply
208-230 V / 60 Hz / 1 Ph
Required Circuit
20 A double-pole
Rated Power (Cooling / Heating / Electric Heater)
1,209 W / 947 W / 3,000 W
Rated Current (Cooling / Heating / Electric Heater)
6.1 A / 4.8 A / 13.6 A
Cooling Operating Range (Outdoor)
63-109°F
Heat Pump Operating Range (Outdoor)
28-75°F
Temperature Setting Range
64-86°F
HEAT PUMP FEATURES
Modes
Cooling, Heating, Dry, Auto, Fan
Air Filters
Washable, reusable
Louvers
Motorized up-down and left-right (dual-axis airflow)
Remote Control
Yes, with Sleep mode and On/Off timer
Wi-Fi
Yes
