Description
DIMENSIONS
- Weight
- About 31.97 lbs/14.5 kg
- Dimensions
- 12.99×8.7×9.53 in
- 33×22.1×24.2 cm
GENERAL INFORMATION
- Charge Temperature
- -4°F to 113°F / -20°C to 45°C
- Discharge Temperature
- -4°F to 113°F / -20°C to 45°C
- Cell Chemistry
- LiFePO₄
- Cycle life
- 6000 cycles to 70%+ capacity
- AC Output
- 120V~ 60Hz, 16.7A Max, 2000W (14°F to 113°F / -10°C to 45°C ) 120V~ 60Hz, 10A Max, 1200W (-4°F to 14°F / -20°C to -10°C )
- AC Total Output
- 2000W Rated, 4000W Surge peak (14°F to 113°F / -10°C to 45°C )
- USB-C Output
- 100W Max, 5V⎓3A, 9V⎓3A, 12V⎓3A, 15V⎓3A, 20V⎓5A (14°F to 113°F / -10°C to 45°C) USB-C Output is off (-4°F to 14°F / -20°C to -10°C) 30W Max, 5V⎓3A, 9V⎓3A, 12V⎓2.5A, 15V⎓2A, 20V⎓1.5A
- USB-A Output
- 18W Max, 5-6V⎓3A, 6-9V⎓2A, 9-12V⎓1.5A
- DC Expansion Port
- 12V⎓10A Max
- AC Input
- Charge Mode: 100-120V~60Hz, 15
- A Max Bypass Mode: 120V~60Hz, 12A Max
- DC Input
- Car: 11-16V⎓8A Max
- Double to 8A Max PV: 16-60V⎓12A Max, Double to 21A Max/ 400W Max
- Folded
- 17.05 × 16.65 × 1.85 in (433 × 423 × 47mm)
- Unfolded
- 65.67 × 16.65 × 0.67 in (1668 × 423 × 17mm)
- General
- x
- Operating Temperature Range
- -4~149℉ (-20°C~65°C)
- Protection Class Against Electric Shock
- Class ll
- Waterproof
- IP68
- Maximum Reverse Current
- 15A
- Bifaciality Coefficient (back/front)
- Pmax: >65%
- Voc: >97%
- Isc: >65%
- Short Circuit Current (Isc)
- 4.1A±5%
TECHNICAL DETAILS
- Maximum System Voltage
- 80V
- Voltage Temperature Coefficient
- -0.25%/°C
- Power Temperature Coefficient
- -0.22%/°C
- Peak Power (Pmax)
- 100W±5%
- Open Circuit Voltage (VOC)
- 29.7V±5%
- Power Voltage (Vmp)
- 25.4V±5%
- Power Current (Imp)
- 3.95A±5%
- Open Circuit Voltage (Voc)
- 30.0V±5%
FEATURES
- Capacity
- 40Ah / 38.4V DC (1536 Wh)
WARRANTY & CERTIFICATIONS
- Warranty
- 3+2
- AC Adapter
- 81 mins
