DoorBird D2100E IP Video Door Station, Engineering Edition for Integration Purposes

Engineering Edition for integration purposes
(GTIN/EAN: 4260423869134, P/N: 423869134)

Highlights

Call buttons and hardware extension modules sold separately
Licensed multi-tenant support and driver for hardware extension modules (MTM14E, MTM18A, Keypad with 12 keys, Keypad with 16 keys, Display Module, Info Module)
LAN connection (PoE capable)
2-way audio
Ultra-wide angle lens, 720p, night vision, 12 IR LEDs
4D motion sensor, RFID reader
2 freely configurable bistable switching relays

Features

Open API - Local interface for integration with third-party systems and SIP
Video and audio call - On smartphones, tablets (iOS, Android), IP and landline phones (SIP)
Smart Transmission Mode (STM) - Real-time audio / video communication, optimized for mobile devices via WiFi, 3G, 4G, 5G
Smart Home & NVR compatible - Control4, Loxone, Crestron, Synology, AVM FRITZ!Fon, URC, QNAP, RTI, ELAN, Fibaro, Bang & Olufsen and others
Automatic door buzzer - For use in medical offices and office environments
Free visitor history - Store still images for free, optional video recording available
Individual action schedules, e.g.:
RFID card “abc” has only access on Wednesday from 9 am until 11 am
4D motion sensor switches on external lamp between 9 pm and 6 am
Geofencing - Automatic door and gate opening when returning home
Night vision - With 12 Infrared LEDs
HDTV Video - Ultra wide-angle, hemispheric lens, 180°
Light sensor - For night vision mode
Microphone - Clear voice transmission
Noise reduction and echo cancellation (AEC, ANR)
RFID reader - Configurable remotely via App (e.g. time frame)
Motion sensor with 4D technology - Distance up to 10 m (32.8 ft) adjustable via App (interval: 1 m/ 3.3 ft)
Easy connection to the network
Connection via a network cable or bell wire via 2-Wire Ethernet PoE Converter “DoorBird A1071” (PoE, network data)
Two freely configurable bi-stable switching relays
Two doors or gates can be controlled via App
Status configurable via App: temporary or permanent circuit

Power supply	15 V DC (max. 15 W) oder Power over Ethernet (PoE 802.3af Mode-A)
Weight	360 g
Connectors	RJ45, for LAN/PoE Bistable latching relay #1, max. 24 V DC / AC, 1 A, e.g. for electric door opener Bistable latching relay #2, max. 24 V DC / AC, 1 A, e.g. for electric door opener External input for external door opener button 15 V DC input (+, -), max. 15 W Relays can be expanded / detached with DoorBird I/O Door Controller
Weather-proof	Yes, IP65
Approvals	IP65, CE, FCC, IC, RoHS, REACH, IEC/EN 62368, IEC/EN 62471
Dimensions	186 x 74 x 48 mm (H x W x D) 7.32 x 2.91 x 1.89 in (H x W x D)
Operating conditions	-25 to +55°C / -13 to 131°F Humidity 10 to 85 % RH (non-condensing)
Scope of delivery	1 x Main Electrical Unit 1 x Holding Plate for mounting the Main Electrical Unit 1x RFID key fob 1x Quickstart guide with Digital Passport 1x Installation manual 1x Small parts
