Front Panel |
3 mm (0.12 in) Available in over 50 RAL colors and surfaces including stainless steel V2A / V4A (see material guide), Graphite Black (Raven Polar) |
Mounting Type |
Flush- or surface-mounted, mounting housing sold separately |
Call Button |
Illuminated |
Nameplate |
Plastic. Engravable metal nameplate sold separately |
Power supply |
15 V DC (max. 15 W) or Power over Ethernet (PoE 802.3af Mode-A) |
Weight |
767 g |
Connectors |
|
Weatherproof |
Yes, IP65 |
Approvals |
IP65, CE, FCC, IC, RoHS, REACH, IEC/EN 62368, IEC/EN 62471 |
Dimensions |
253 x 131 x 48,75 mm (H x W x D) 9.96 x 5.16 x 1.92 in (H x W x D) |
Operating conditions |
-25 to +55°C / -13 to 131°F Humidity 10 to 85 % RH (non condensing) |
Scope of delivery |
1x Main Electrical Unit 1x Front panel 1x RFID key fob 1x Screwdriver 1x Quickstart guide with Digital Passport 1x Installation manual 1x Small parts |
