Description
DIMENSIONS & WEIGHT
- Weight
- 570 g
- Dimensions
- 171.9 x 85 x 32 mm (H x W x D) 6.77 x 3.35 x 1.26 in (H x W x D)
GENERAL INFORMATION
- Mounting Type
- Flush-mounted, surface-mounted version sold separately
DESIGN & MATERIALS
- Front Panel
- 3 mm (0.12 in), For further materials and colours see material board and Online Shop.
- Mounting Housing (backbox)
- Stainless steel
POWER & CONNECTIVITY
- Power supply
- 15 V DC (max. 15 W) or Power over Ethernet (PoE 802.3af Mode-A)
- Connectors
- LAN/PoE (T+, T-, R+, R-)
- Bistable latching relay, max. 1-24 V DC/AC, 1 A, e.g. for electric door opener
- External input for external door opener button
- 15 V DC input (+, -), max. 15 W
- Relays can be expanded / detached with DoorBird I/O Door Controller
FEATURES
- Call button
- Illuminated
DURABILITY & ENVIRONMENT
- Protection Class
- IP65, IK08
- Approvals
- CE, UKCA, FCC, IC, RoHS, REACH, WEEE, Wi-Fi CERTIFIED™
- Operating Conditions
- -25 to +55°C / -13 to 131°F Humidity 10 to 85 % RH (non-condensing)
IN THE BOX
- Scope of Delivery
- 1x Main Electrical Unit
- 1x Front panel
- 1x Flush-mounting housing (backbox)
- 1x Power supply unit (mains adaptor) with up to 4 country-specific outlet adaptors (100 - 240 V AC to 15 V DC)
- 1x RJ45 adapter
- 1x Screwdriver
- 1x Quickstart guide with Digital Passport
- 1x Installation manual
- 1x Small parts
