Description
DIMENSIONS & WEIGHT
- Unit Dimensions
- 30-5/16 W" x 9-11/16 D" x 11-5/16 H"
- Unit Weight
- 20.3 lbs
- Pallet Qty
- 16
GENERAL INFORMATION
- Brand
- Daikin
- Product Family
- FTXC_AXVJU
- Family Description
- 0.75 - 2 Ton 18 Series Wall Mount Air Handler
- Unit Type
- Indoor
- Product Class
- Mini-Split Wall Mount Air Handler
- Vendor
- Daikin Comfort Tech
- Product Benefits
- 10 Year Limited Parts Warranty with Online Registration
- Standard Features
- Sound Pressure as low as 19 dB(A)
- Series
- Daikin Entra
CAPACITY & PERFORMANCE
- Tonnage
- 0.75 Ton
- Cooling Capacity (Rated)
- 9,000 Btu/H
- Heating Capacity (Rated)
- 9,400 Btu/H
- Airflow Rate High (Cooling)
- 431 ft³/min
- Airflow Rate High (Heating)
- 402 ft³/min
- SEER2 (Matched System)
- 18
- HSPF2 (Matched System)
- 9
- EER2 (Matched System)
- 11
NOISE LEVELS
- Sound Pressure (High)
- 43 dB(A)
- Sound Pressure (Silent)
- 19 dB(A)
ELECTRICAL REQUIREMENTS
- Power Voltage
- 208-230 V
- Power Phase
- 1 Ph
- Power Frequency
- 60 Hz
REFRIGERANT & PIPING
- Refrigerant Type
- R-32
- Pipe Size Gas
- 3/8 in
- Pipe Size Liquid
- 1/4 in
- Line Set
- Not included (sold separately)
WARRANTY
- Registered Parts Warranty - Residential
- All Parts - 10 Years
- Registered Parts Warranty - Multi-Family
- All Parts - 10 Years
- Registered Parts Warranty - Commercial
- All Parts - 5 Years
- Standard Parts Warranty - Residential
- All Parts - 5 Years
- Standard Parts Warranty - Multi-Family
- All Parts - 5 Years
- Standard Parts Warranty - Commercial
- All Parts - 5 Years
CONTROLS & CONNECTIVITY
- Wi-Fi
- Optional adapter (AZAI6WSCDKB DKN Cloud Wi-Fi adapter)
