Description
DIMENSIONS
- Product Dimensions (WxDxH)
- 35 1/4″ x 20 11/16″ x 23 7/16″ - 40 11/16″
- Packing-Box Size (WxDxH)
- 39 5/8″ x 28 3/16″ x 24 1/4″
- Net Weight (lb)
- 62.4
- Gross Weight (lb)
- 78.9
GENERAL INFORMATION
- Installation
- Wall Mount
- Duct Type
- Vertical
PERFORMANCE
- Max Equivalent CFM
- 1200 CFM
- CFM (HVI)
- 257 / 416 / 540 / 651
- Motor
- DC Motor
- Motor Power
- 290W
- Speed Setting
- 4
- Noise Level (dB)
- 37 / 45.4 / 51.5 / 56.2
- Max Static Pressure
- 1000 Pa
- Oil Filtration Rate
- 95%
- Odor Elimination Rate
- 97%
FEATURES & CONTROLS
- Capture Shield
- Fixed / Combined With Oil Cup (2nd Generation)
- Control Type
- Touch + Motion
- Delay Shutoff
- 2 min
- Screen Lock
- Y
- Boost
- Yes
- Illumination
- 5W x 1 (LED), up to 700 Lux
- Oil Filter
- Removable & Dishwasher Safe
DESIGN & FINISH
- Color
- Stainless Steel
TECHNICAL DETAILS
- Power Supply
- 120V / 60Hz
- Duct Size
- 6″ Round (Top Vented)
WARRANTY & CERTIFICATIONS
- Warranty
- 5-Year Limited (2-Year Labor, 5-Year Parts, Lifetime Motor)
- Certification
- ETL, HVI, CEC
