Description
DIMENSIONS
- Product Dimensions (WxDxH)
- 35 7/8″ x 18 7/16″ x 17 7/16″
- Packing-Box Size (WxDxH)
- 43 5/8″ x 26 3/4″ x 27 3/8″
GENERAL INFORMATION
- Installation
- Under Cabinet / Wall Mount
- Duct Type
- Vertical
PERFORMANCE
- Max. EQUIV. CFM
- 1000
- CFM (HVI)
- 220 / 410 / 520 / 580
- Motor
- Dual DC Motors
- Motor Power
- 210W
- Max Static Pressure
- 540 Pa
- Speed Setting
- 4
- Noise Level (dB)
- 38.5 / 48.2 / 54 / 56.5
- Oil Filtration Rate
- 95%
- Odor Elimination Rate
- 98%
- Cooking Area Coverage
- 6 ft² (5-6 Burners)
FEATURES & CONTROLS
- Control Type
- Touch + Motion
- Capture Shield
- Auto (90°)
- Delay Shutoff
- 2 min
- Screen Lock
- Y
- Motion Activation
- Yes
- Stir-Fry Mode
- Yes
- Oil Cup
- One Oversized Oil Cup
- Oil Filter
- Removable & Dishwasher Safe
DESIGN & FINISH
- Surface
- Black Tempered Glass
- Illumination
- 3W x 2 (LED)
TECHNICAL DETAILS
- Power Supply
- 120V / 60Hz
- Duct Size
- 6″ Round (top vented)
WARRANTY & CERTIFICATIONS
- Certification
- ETL, HVI, CEC
- Warranty
- 5-Year Limited (2-Year Labor, 5-Year Parts, Lifetime Motor)
