Description
DIMENSIONS
- Product Dimensions
- 30" W x 21" D x 6" H
- Cut-Out Dimension
- Min 28 1/2” – Max 29“ W x Min 19 5/8” – Max 20 1/8“ D
- Net Weight(lb)
- 57.3 lbs.
- Gross Weight(lb)
- 67.7 lbs.
GENERAL INFORMATION
- Gas Type
- NG/LPG
- Installation Type
- Built-In
- Propane (LP) Convertible
- Yes
- Propane Conversion Kit Included
- Yes
DESIGN & FINISH
- Color of Frame / Surface
- Black
TECHNICAL DETAILS
- Power Cord Included
- Yes
- Power Cord Length
- 51 3/16 total, 39 3/8 outside (some parts are inside the cooktop bottom)
FEATURES
- Build-in Size
- 28 1/4“ W x 19 1/4” D x 3 1/4“ H
- Packing-Box Size
- 35 7/8” W x 25 1/4“ D x 9 7/8“ H
- No. of Burner
- 3
- Grate Material
- Cast Iron
- Heating Load(BTU)
- L: 18000 BTU
- M: 5800 BTU
- R: 13200 BTU
- Energy Source
- Gas
- Commercial/Residential
- Residential
- Type of Grate
- Continuous
- Power Supply
- 120V / 60 Hz
- Burner Sealness
- Sealed Burners
- Safety Device for Gas
- Yes
- Safety Device/Ignition Type
- Flame Failure Device / Fast ignition
- Location of Gas Connection
- Bottom
- Accessories Included
- 3 Cast Iron Grates
- 3 Burners
- 1 Wok Ring
- 1 Tea Kettle Grate
- 1 User Manuals
- 1 Installation Kit
- 1 Propane (LP) Conversion Kit
WARRANTY & CERTIFICATIONS
- Warranty
- 1-Year Full, 5-Year Limited on Parts
