Description
- Net Dimensions (In)
- 12.99 D 21.81 H 31.69 W
- Net Weight (Lbs)
- 72.31
- Gross Depth (In)
- 14.57
- Gross Height (In)
- 24.21
- Gross Width (In)
- 36.02
- Gross Weight (Lbs)
- 79.59
- Color
- White
- Max Coverage Area
- 550
- Inverter
- Yes
- Metering Device
- EEV
- SEER2
- 23.5
- EER2
- 12.8
- HSPF2-4
- 10
- HSPF2-5
- 8
- CFM
- 1471.5
- Tonnage
- 1
- Cooling Capacity (BTU)
- 12000
- Heating Capacity (BTU)
- 12000
- Cycle
- 60
- Min Ambient Cool (F)
- -22
- Min Ambient Heat (F)
- -22
- Compressor Motor Type
- Rotary
- Condenser Fan Motor Rpm
- 780/680/580
- Decibel Rating (Dba)
- 56.5
- Voltage (V)
- 208/230
- Phase
- 1
- Max Fuse Breaker (A)
- 15
- Min Circuit Ampacity (A)
- 15
- Refrigerant Type
- R-454B
- Refrigerant Volume (Oz)
- 32.1
- Lineset Included
- Yes
- Line Set Length
- 25ft
- Max Lineset Length (Ft)
- 75
- Liquid Line Size
- 1/4
- Suction Line Size
- 3/8
- Works With
- DIYCASSETTE12HP-230D25-O DIY-12-HP-WMAH-230D25-O
- UL Listed
- Yes
- CSA Certified
- Yes
- ETL Certified
- Yes
- Energy Star Certified
- Yes
- AHRI Certified
- Yes
- Contains Electronics
- Yes
- Contains Chemicals
- Yes
- Contains Compressed Gas
- Yes
- Proposition 65 Warning
- Yes
- Restricted States
- GU
- PR
- VI
- Registered Warranty
- 7-Years Compressor, 5-Years Parts
- Base Warranty
- 5-Years Parts
- Base Parts Warranty
- 5 Years
- Base Compressor Warranty
- 7 Years
