Description
DIMENSIONS
- Product Dimensions (WxDxH)
- 35 7/8″ x 18 7/16″ x 17 7/16″
- Packing-Box Size (WxDxH)
- 43 5/8″ x 26 3/4″ x 27 3/8″
- Net Weight (lb)
- 70.1
- Gross Weight (lb)
- 91.9
GENERAL INFORMATION
- Installation
- Under Cabinet / Wall Mount
- Duct Type
- Vertical
PERFORMANCE
- Max EQUIV. CFM
- 1100
- CFM (CEC)
- 230 / 420 / 520 / 580
- CFM (HVI)
- 220 / 410 / 520 / 580
- Max Static Pressure
- 540 Pa
- Motor
- Dual DC Motors
- Motor Power
- 210W
- Speed Settings
- 4
- Noise Level (dB)
- 38.5 / 48.2 / 54.0 / 56.5
- Oil Filtration Rate
- 95%
- Odor Elimination Rate
- 98%
FEATURES & CONTROLS
- Control Type
- Touch + Motion
- Capture Shield
- 90° Automatic
- Delay Shutoff
- 5 min
- Screen Lock
- Y
- Stir-Fry Mode
- Yes
- Sync Connect
- Yes
- Illumination
- 3W x 2 (LED)
DESIGN & FINISH
- Color
- Moonshadow
TECHNICAL DETAILS
- Power Supply
- 120V / 60Hz
WARRANTY & CERTIFICATIONS
- Certification
- ETL, FCC
Authorized FOTILE Dealer
Full manufacturer warranty on every FOTILE product we sell.
