Description
DIMENSIONS
- Product Dimensions (W x D x H)
- 35 7/8" x 18 7/16" x 17 7/16"
- Packing-Box Size (W x D x H)
- 43 5/8" × 26 3/4" × 27 3/8"
GENERAL INFORMATION
- Brand
- FOTILE
- Series
- JQG07 Inclined Vent
- Model
- JQG9007-W
- Type
- Range Hood
- Size
- 36"
- Installation
- Under Cabinet / Wall Mount
- Duct Type
- Vertical
DESIGN & FINISH
- Color
- White
- Illumination
- 3W × 2 (LED)
- Capture Shield
- Auto
TECHNICAL DETAILS
- Power Supply
- 120V / 60Hz
- Motor
- Dual DC Motors
- Motor Power
- 210W
- Input Power
- 210W
- Max Static Pressure
- 540 Pa
- Control Type
- Touch + Motion
- Speed Setting
- 4
PERFORMANCE & FEATURES
- Max. EQUIV. CFM
- 1100 CFM*
- CFM (CEC)
- Speed 1: 230
- Speed 2: 420
- Speed 3: 520
- Speed 4: 580
- CFM (HVI)
- Speed 1: 220
- Speed 2: 410
- Speed 3: 520
- Speed 4: 580
- Noise Level (Sones)
- Speed 1: 1.2
- Speed 2: 4
- Speed 3: 6.5
- Speed 4: 7.5
- Noise Level (dB)
- Speed 1: 38.5
- Speed 2: 48.2
- Speed 3: 54.0
- Speed 4: 56.5
- Oil Cup
- One Oversized Oil Cup
- Oil Filter
- Removable & Dishwasher Safe
- Delay Shutoff
- 5 min.
- Screen Lock
- Yes
- Boost
- Yes
- Oil Filtration Rate
- 95%
- Odor Elimination Rate
- 98%
WARRANTY & CERTIFICATIONS
- Certifications
- ETL, FCC
