Description
DIMENSIONS
- Product Dimensions (WxDxH) (inch)
- 36" x 21" x 6 5/16"
- Chassis Dimensions (WxD) (inch)
- 33 9/16" x 18 7/8"
- Cut-Out Dimension (WxD) (inch)
- 33 7/8" x 19 1/8"
- Net Weight (lb.)
- 70.1 lbs
- Gross Weight (lb.)
- 80.5 lbs
GENERAL INFORMATION
- Gas Type
- NG/LPG
- Installation Type
- Built-In
- Propane (LPG) Convertible
- Yes
- Propane Conversion Kit Included
- Yes
TECHNICAL DETAILS
- Power Cord Included
- Yes
- Power Cord Length (inch)
- 51 3/16" total, 39 13/16" outside (some parts are inside the cooktop bottom)
FEATURES
- Packing-Box Size (WxDxH) (inch)
- 39 15/16" x 24" x 9 15/16"
- No. of Burner
- 5
- Grate Material
- Cast Iron
- Heating Load (BTU)
- L: 18000BTU MF: 5800BTU MR: 13200BTU RF: 13200BTU RR: 3000BTU
- Energy Source
- Gas
- Commercial/Residential
- Residential
- Type of Grate
- Continuous
- Power Supply
- 120V / 60 Hz
- Burner Seams
- Sealed Burners
- Safety Device for Gas
- Yes
- Safety Device/Ignition Type
- Flame Failure Device / Fast ignition
- Location of Gas Connection
- Bottom
- Accessories Included
- 3 Cast Iron Grate
- 5 Iron Burners
- 1 Regulator
- 1 Jet Kettle Grate
- 1 User Manual
- 1 Installation Kit
- 1 Propane (LPG) Conversion Kit
WARRANTY & CERTIFICATIONS
- Certification
- CSA
- Warranty
- 1-Year Full, 5-Year Limited on Parts
