Description
DIMENSIONS
- Product Dimensions (WxDxH)
- 30" x 21" x 6"
- Cut-Out Dimension (WxD)
- Min 28 1/2" – Max 29" x Min 19 5/8" – Max 20 1/8"
- Net Weight (lb.)
- 58 lbs.
- Gross Weight (lb.)
- 68.3 lbs.
GENERAL INFORMATION
- Gas Type
- NG/LPG
- Installation Type
- Built-In
- Propane (LP) Convertible
- Yes
- Propane Conversion Kit Included
- Yes
DESIGN & FINISH
- Color of Frame / Surface
- MOONSHADOW: GLG30401-Y Black: GLG30401
TECHNICAL DETAILS
- Power Cord Included
- Yes
- Power Cord Length (inch)
- 51 3/16" total, 39 13/16" outside (some parts are inside the cooktop bottom)
FEATURES
- Build-in Size (WxDxH)
- 28 1/4" x 19 1/4" x 4 3/16"
- Packing-Box Size (WxDxH)
- 35 7/8" x 25 1/4" x 9 7/8"
- No. of Burner
- 4
- Grate Material
- Cast Iron
- Heating Load(BTU)
- L: 18000 BTU
- MR: 5800 BTU
- MF: 3000 BTU
- R: 13200 BTU
- Energy Source
- GAS
- Commercial/Residential
- Residential
- Type of Grate
- Continuous
- Power Supply
- 120V / 60 Hz
- Burner Sealness
- Sealed Burners
- Safety Device for Gas
- Yes
- Safety Device/Ignition Type
- Flame Failure Device / Fast ignition
- Location of Gas Connection
- Bottom
- Accessories Included
- 3 Cast Iron Grate
- 4 Burners
- 1 Wok Ring
- 1 Tea Kettle Grate
- 1 User Manuals
- 1 Installation Kit
- 1 Propane (LP) Conversion Kit
WARRANTY & CERTIFICATIONS
- Warranty
- 1-Year Full, 5-Year Limited on Parts
