Tucked neatly out of sight within your cabinetry, Pisa is a minimal alternative to your typical under-cabinet range hood. Adorned with LumiLight LED Lighting and powered by the strength of a 500-CFM or 290-CFM blower, Pisa’s low-profile body delivers stunning design and quality performance. Its retractable visor helps with the capture of air and puts control at your fingertips. Pisa is ideal for kitchens that require a more discreet, sophisticated look.
| Nominal Width; IN | 24 |
| Net Width; IN | 23.875 |
| Net Depth; IN | 11.125 |
| Net Height; IN | 11.25 |
| Weight; LBS | 28 |
| Finish | White |
| Primary Material | Steel |
| Installation Type | Under Cabinet |
| Vent Type | Convertible |
| Controls Type | Mechanical Slide |
| Blower Included | Yes |
| Internal Blower 1 CFM | 500 |
| Internal Blower 1 Min. Sones | 1.7 |
| Internal Blower 1 Max Sones | 5.3 |
| Minimum CFM | 230 |
| For Outdoor Use | No |
| Blower Speeds | 3 |
| Automatic Delay-Off | No |
| Clean Air Function | No |
| Lighting Type | LED |
| Lights Quantity | 1 |
| Watts Per Bulb | 6 |
| Lights Levels | 2 |
| Grease Filter Type | Mesh |
| Compatible Mesh or Baffle Filter Part Number | 50200054 |
| Duct Discharge | Vertical or Horizontal |
| Duct Size; Horizontal; IN | 6 |
| Duct Size; Vertical; IN | 6 |
| Mounting Height Above Cooktop; IN | 20 - 32 |
| Voltage | 120 |
| Maximum Amperage | 3 |
| ADA Compliant | No |
| Energy Star Certified | No |
