Ultimate Guide to Wiring Your DoorBird Door Controller with an Electric Strike

Imagine never having to worry about fumbling for keys again. The DoorBird Door Controller is an advanced access control system that integrates seamlessly with electric strikes to provide secure and convenient entry solutions. Electric strikes are electromechanical door-locking devices used for controlling access.

Proper wiring ensures the door controller and electric strike work efficiently and securely. Incorrect wiring can lead to security vulnerabilities and functional issues.

This guide will walk you through the process of wiring your door controller with an electric strike, covering everything from basic concepts to advanced configurations.

Understanding the Basics

To successfully wire your DoorBird Door Controller with an electric strike, it's important to understand the core components and their functionality.

A DoorBird Door Controller is an IP-based access control device that allows you to remotely manage and monitor entry points through a smartphone app. It combines video intercom and doorbell functionalities with advanced security features.

What is an Electric Strike?

An electric strike is an electromechanical door-locking mechanism that remains locked until an electric current releases the latch. It allows for controlled access and is commonly used in conjunction with access control systems like the DoorBird Door Controller.

How Do They Work Together?

When connected, the DoorBird Door Controller signals the electric strike to unlock the door, providing a secure and smart entry solution.

Pre-Wiring Preparations

Before you start wiring, gather all the necessary tools and materials and familiarize yourself with safety precautions and the wiring diagram. You’ll need screwdrivers, wire strippers, a drill, electrical tape, a multimeter, wiring connectors, the DoorBird Door Controller, an electric strike, and a power supply.

Safety Precautions

Ensure the power is turned off before starting any wiring work to prevent electric shocks. Wear safety gloves and goggles, and double-check all connections before turning the power back on. Keep your workspace organized to avoid accidents.

Understanding the Wiring Diagram

The wiring diagram illustrates connecting the door controller to the electric strike and power source. Study the diagram carefully, noting the color-coded wires and connection points to ensure accurate and secure wiring. This is vital for ensuring the functionality of your network door controller.

tamperproof control

Step-by-Step Wiring Instructions

With your DoorBird Door Controller and electric strike in hand, you're ready to start the wiring process. These detailed instructions will guide you through each step, ensuring you connect everything correctly and securely. By following this guide, you'll make the installation process straightforward and efficient.

Gathering Necessary Information

When it comes to the wiring process, it's important to gather all the needed information. First, check the compatibility of your door controller and electric strike with your existing door and access system. Next, carefully read the manufacturer's manuals for both the door controller and the electric strike to get specific wiring diagrams and detailed setup guidelines tailored to your devices.

Setting Up the DoorBird Door Controller

Begin by unpacking and inspecting your DoorBird Door Controller to ensure all components are present and undamaged. Familiarize yourself with each part and its function. Next, mount the door controller in an optimal location for accessibility and security, following the manufacturer's guidelines. This device is capable of controlling access for up to three doors, making it a versatile solution for various entry points. Ensure the door controllers are securely attached and properly aligned for the best performance.

Preparing the Electric Strike

Proper preparation of the electric strike is essential for seamless integration with your DoorBird Door Controller. Understanding the different types of electric strikes and choosing the right one for your setup will ensure optimal performance.

Types of Electric Strikes

Electric strikes come in various types, each suited for different security needs and door types. Common types include fail-secure, fail-safe, and continuous duty strikes. Fail-secure strikes remain locked during a power outage, while fail-safe strikes unlock. Continuous duty strikes are designed for high-traffic areas.

Choosing the Right Electric Strike

Selecting the right electric strike depends on your specific access points and security requirements. Consider factors such as the door material, usage frequency, and whether you need integration with switching relays or external sensors. Ensure the electric strike meets banking standards monitoring for high-security applications.

Installing the Electric Strike

Begin by following the manufacturer’s installation guide to correctly position the electric strike on the door frame. Secure it using the provided screws and connectors. Make sure the electric strike is aligned properly with the door latch to ensure smooth operation. If needed, consult a professional for precise installation.

Wiring the DoorBird Door Controller

To wire your DoorBird Door Controller, start by identifying the wiring connections based on the manufacturer's diagram. Connect the power supply to ensure the device receives the necessary electricity. Next, connect the controller to the network, either through Wi-Fi or an Ethernet cable, depending on your setup. Make sure all connections are secure and follow the guidelines provided in the manual to avoid any issues.

Wiring the Electric Strike

To wire the electric strike, start by understanding the basics, including the different wire colors and their functions. Typically, you’ll have wires for power, ground, and signal connections. Connect the electric strike to the DoorBird Door Controller by following the wiring diagram provided. Ensure each wire is connected to the corresponding terminal on both the strike and the controller. After wiring, test the connections by powering on the system and verifying that the electric strike operates as expected when triggered by the DoorBird Door Controller. Make any necessary adjustments to ensure smooth operation.

Advanced Wiring Configurations

To integrate your door controller with an intercom system, connect the corresponding wires from the intercom to the door controller following the manufacturer’s instructions. This setup allows you to communicate with visitors before granting access.

Connecting to a Smart Home System

Connect the DoorBird Door Controller to your smart home hub via Wi-Fi or Ethernet for smart home integration. Configure the settings in your smart home app to include the door controller in your automation routines, enhancing convenience and security.

Using a Backup Power Source

Ensure uninterrupted operation by using a backup power source. Connect a battery backup or an uninterruptible power supply (UPS) to the DoorBird Door Controller. This ensures the system remains functional during power outages, maintaining security and accessibility.

Troubleshooting Common Issues

Even with careful installation, you may encounter some common issues with your DoorBird Door Controller and electric strike. Here are solutions to some frequent problems to help you troubleshoot effectively.

No Power to the Door Controller

Ensure that the power supply is properly connected and functioning. Check for any loose wires or disconnected cables. If you're using bi-stable switching relays, verify that it is correctly installed and configured.

Electric Strike Not Engaging

Check the wiring connections between the door controller and the electric strike. Ensure that the power is reaching the strike. If the issue persists, verify that any two external sensors used are functioning properly and not interfering with the strike’s operation.

Network Connectivity Problems

Confirm that the door controller is connected to your network via Wi-Fi or Ethernet. Check your router settings and ensure that the device is within range. Freely configurable network settings might help resolve any connectivity issues.

Safety and Maintenance Tips

To ensure your door controller and electric strike remain in optimal condition, perform regular inspections and testing to identify any issues early. Keep the firmware and software updated to benefit from the latest features and security improvements. Always ensure secure connections by checking that all wires and components are tightly connected and functioning correctly. Regular maintenance will help prevent potential problems and extend the lifespan of your security system.

Summary

Wiring your DoorBird Door Controller with an electric strike is a detailed process that, when done correctly, ensures a secure and efficient access control system. Following instructions carefully at each step is crucial to avoid errors and ensure the longevity of your setup. This includes checking compatibility, understanding the wiring diagram, and ensuring all connections are secure.

Final testing and verification are essential to confirm that the system operates correctly. Power up the system, test the door controller and electric strike and ensure network connectivity. Address any issues immediately to prevent future problems. Regular maintenance, such as updating firmware and conducting inspections, will keep your system in optimal condition and help you take advantage of the latest security features.
