Pioneer Diamante Pro Series 36,000 BTU, 19 SEER2, Ductless Mini-Split Air Conditioner Inverter+ and Heat Pump Full Set, 230V with 16 Ft. Lineset, available at Home Outlet Direct.
|
Performance Data |
|
| Power Supply: |
208~230V, 60Hz, 1Ph |
| Cooling Rated Capacity: |
36,000 BTU/h |
| Cooling Capacity Range: |
10,800~39,600 BTU/h |
| Cooling SEER2: |
19 BTU/W.h |
| Cooling EER2: |
9 BTU/W.h |
| Heating Rated Capacity: |
36,000 BTU/h |
| Heating Capacity Range: |
10,800~39,600 BTU/h |
| Heating HSPF2 (Region IV/V): |
8.5 / 7.0 BTU/W.h |
| Heating C.O.P.2 (47°F/5°F): |
3.01 / 1.75 W/W |
| Refrigerant Type: |
R410A |
| Suitable Area: |
900~1,250 Sq.F |
|
Indoor Unit Data |
|
| Part Number: |
WT036GLFI19HLE |
| Air Flow (Hi/Med/Lo): |
847 / 700 / 641 CFM |
| Sound Level (Hi/Med/Lo): |
48 / 43 / 38 dB(A) |
| Net Dimensions (WDH): |
47 x 10-1/4 x 14-1/4 Inches |
| Carton Dimensions (WDH): |
49-3/4 x 13-1/4 x 17-1/4 Inches |
| Net / Gross Weight: |
39.7 / 48.5 lbs |
|
Outdoor Unit Data |
|
| Part Number: |
YN036GLFI19RPE |
| Breaker Needed: |
25A (double-pole) |
| Sound Level: |
63 dB(A) |
| Net Dimensions (WDH): |
35-3/4 x 14-1/8 x 31-1/2 Inches |
| Carton Dimensions (WDH): |
40-1/2 x 18-3/4 x 34 Inches |
| Net / Gross Weight: |
114.6 / 126.8 lbs |
What BTU rating should I choose for my air handler?
| Air Handler BTU | Coverage Area/Room Size (Sq Ft.)* |
| 9K BTU | Up to 375 Sq. ft |
| 12K BTU | Up to 500 Sq. ft |
| 18K BTU | Up to 750 Sq. ft |
| 24k BTU | Up to 1000 Sq. ft |
| 36k BTU | Up to 1500 Sq. ft |
*Ceiling height, insulation, and local climate may impact the coverage area. For example, an uninsulated room will require more power than a well insulated room.
