SKU: 423870796
$2,184.48 $2,299.99

Finish: Stainless Steel V4A
Type
Out of Stock No restock estimate
  • Secure Payment
    Amazon American Express Apple Pay Diners Club Discover Google Pay Mastercard PayPal Shop Pay Venmo Visa
    Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
  • Free Shipping*
  • 30-Day Return Policy⁺

Description

DoorBird D2104V IP Video Door Station, 4 Call Button in Stainless Steel V4A

For multi-tenant buildings and businesses with 4 units, 4 call buttons
Stainless steel V4A (salt-water and grinding dust resistant), brushed
(GTIN/EAN: 4260423870796, P/N: 423870796)

Highlights

  • Surface- and flush-mount possible, housings sold separately
  • LAN connection (PoE capable)
  • 2-way audio
  • Ultra-wide angle lens, 720p, night vision, 12 IR LEDs
  • 4D motion sensor, RFID reader
  • 2 freely configurable bistable switching relays

Features

  • Open API: Local interface for integration with third-party systems and SIP
  • Video and audio call: On smartphones, tablets (iOS, Android), IP and landline phones (SIP)
  • Smart Transmission Mode (STM): Real-time audio / video communication, optimized for mobile devices via WiFi, 3G, 4G, 5G
  • Smart Home & NVR compatible: Control4, Loxone, Crestron, Synology, AVM FRITZ!Fon, URC, QNAP, RTI, ELAN, Fibaro, Bang & Olufsen and others
  • Automatic door buzzer: For use in medical offices and office environments
  • Individual action schedules, e.g.: RFID card “abc” has only access on Wednesday from 9 am until 11 am. 4D motion sensor switches on external lamp between 9 pm and 6 am
  • Geofencing: Automatic door and gate opening when returning home
  • Night vision: With 12 Infrared LEDs
  • HDTV Video: Ultra wide-angle, hemispheric lens, 180°
  • Light sensor: For night vision mode
  • Microphone: Clear voice transmission
  • Noise reduction and echo cancellation (AEC, ANR)
  • RFID reader: Configurable remotely via App (e.g. time frame)
  • Motion sensor with 4D technology: Distance up to 10 m (32.8 ft) adjustable via App (interval: 1 m/ 3.3 ft)
  • Call button: With backlit nameplate
  • Easy connection to the network: Connection via a network cable or bell wire via 2-Wire Ethernet PoE Converter “DoorBird A1071” (PoE, network data)
  • Two freely configurable bi-stable switching relays: Two doors or gates can be controlled via App. Status configurable via App: temporary or permanent circuit

Accessories

DIMENSIONS & WEIGHT
Weight 1208 g
Dimensions 403 x 131 x 45,75 mm (H x W x D) 15.87 x 5.16 x 1.80 in (H x W x D)
GENERAL INFORMATION
Mounting Type Flush- or surface-mounted, mounting housing sold separately
DESIGN & MATERIALS
Front Panel 3 mm (0.12 in) Available in brushed stainless steel V2A / V4A and V2A with bronze and titanium finish, DB 703, RAL 7016, Graphite Black (Raven Polar)
POWER & CONNECTIVITY
Power supply 15 V DC (max. 15 W) or Power over Ethernet (PoE 802.3af Mode-A)
Connectors
  • RJ45, for LAN/PoE
  • Bistable latching relay #1, max. 24 V DC / AC, 1 Ampere, e.g. for electric door opener
  • Bistable latching relay #2, max. 24 V DC / AC, 1 Ampere, e.g. for electric door opener
  • External input for external door opener button
  • 15 V DC input (+, -), max. 15 W
  • Relays can be expanded / detached with DoorBird I/O Door Controller
FEATURES
Call Button Illuminated
Nameplate Plastic. Engravable metal nameplate sold separately
DURABILITY & ENVIRONMENT
Weatherproof Yes, IP65
Approvals IP65, CE, FCC, IC, RoHS, IK08, REACH, IEC/EN 62368, IEC/EN 62471
Operating conditions -25 to +55°C / -13 to 131°F Humidity 10 to 85 % RH (non condensing)
IN THE BOX
Scope of delivery
  • 1x Main Electrical Unit
  • 1x Front panel
  • 1x RFID key fob
  • 1x Screwdriver
  • 1x Quickstart guide with Digital Passport
  • 1x Installation manual
  • 1x Small parts
