| Dimensions | 52" H x 32" D x 25.75" W |
| AHRI Certified | Yes |
| ASHRAE Compliant | No |
| Base Warranty | 5 year limited parts warranty |
| Blower Motor Hp | 3/4 |
| Blower Motor Type | Axial Flux (No Shaft) BLA |
| Color | Gray |
|
Color Family
|
Gray |
|
Compressor Motor Type
|
Scroll |
|
Contains Aerosol
|
Yes |
|
Contains Chemicals
|
Yes |
|
Contains Compressed Gas
|
Yes |
| Contains Electronics | Yes |
| Cooling Capacity | 57000 |
| COP 47 | 4.0-4.97 |
| COP 47 Part Load | 4.5-5.29 |
| Cycle | 60 |
| EER | 19.4-25.8 |
| EER Part Load | 26.1-32.8 |
| Energy Star Certified | Yes |
| Energy Star Compliant | Yes |
| ETL Certified | No |
| ETL Listed | Yes |
| Filter Size | 36X30 |
| Filter Type | Replaceable |
| Freight Class | 85 |
| Has Batteries | No |
| Heating Capacity | 57000 |
| LEED Certified | No |
| Max Coverage Area | 2500 |
| Max Fuse Breaker | 64(W/O Desuperh |
| Min Circuit Ampacity | 38.6 |
| Net Weight | 365 |
| Phase | 1 |
| Proposition 65 Warning | Yes |
| Refrigerant Type | R-410A |
| Registered Warranty | 10 year registered parts limited warranty & 10 year compressor warranty |
| Restricted States | No |
| Stage | Two-Stage |
| Tonnage | 5 |
| UL Listed | No |
| UL Reconized | No |
| Voltage | 230 |
*Shipping Policy
Installed my own central HP system. It was a bit of work but nothing beyond a person with basic mechanical and electrical skills. It took me a while because I had to remove the existing electric forced air furnace from a pretty tight place. Some custom sheet metal work and a bit of custom electrical too. Worked perfectly when powered up and I actually like the thermostat provided, although I wish it was clearer how to set up a temperature set-back schedule. Pre-charged refrigerant piping was something new and I liked that too. The best thing is that my electric utility forked out $4,000 and that paid for the unit!
Installed with ceiling cassettes... Quiet and keeping us cool so far !
I recently removed my old gas furnace and replaced it with the MRCOOL Hyper Heat - Central Heat Pump & Gas Furnace Split System - 24K BTU, 96% AFUE - 17.5" Cabinet - Multi-Position. This system was very straight forward and simple to install. I live in Colorado and have been enjoying the cool all summer. I tested the heat function but have not had a cold season yet, with my new system. I'm sure it will heat as good as it cools.
My installation was complex because the room where I installed the units has a challenging layout. The units seem to work well, but I hear the sound of freon flowing inside the pipes, and I wonder if this is normal or if I made a mistake. Sometimes, the pipe insulators have drops of water from internal condensation, which also concerns me. I was unable to reach tech support to address these questions. I spent almost $4,700 in cash, and not being able to reach tech support is unacceptable.
No muss, no fuss. 1 call about extended warranty which I declined. Otherwise just straight forward drop shipment to curb, on time and as expected. All items in perfect shape, no breaks or rips in boxes.
The items (Mr. Cool 27k 3 head 9k/9k/12k DIY) installed great, easy to follow instructions. 1 wall insert was slightly cracked due to no packing material in the line box, but I it taped up and it inserted fine. Could have used more custom sized lines for fitting but otherwise very happy with product.
