MRCOOL GeoCool 60K BTU, 5 Ton, Horizontal Two-Stage CuNi Coil Left Return w/ Desuperheater (GCHPH060TGTANDL)

MRCOOL GeoCool 60K BTU, 5 Ton, Horizontal Two-Stage CuNi Coil Left Return w/ Desuperheater (GCHPH060TGTANDL)


Sale price$7,061.00 Regular price$7,999.00
Save 12%

Estimated delivery:
  • Secure Payment
    Amazon American Express Apple Pay Diners Club Discover Google Pay Mastercard PayPal Shop Pay Venmo Visa
    Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
  • Free Shipping*
  • 30-Day Return Policy⁺


MRCOOL GeoCool 60K BTU, 5 Ton, Horizontal Two-Stage CuNi Coil Left Return w/ Desuperheater (GCHPH060TGTANDL)


  • Qualifies for federal tax credit, and other incentives
  • Highest energy efficiency in its class
  • Safety high and low pressure switches
  • Quiet operation
  • Full featured sinusoidal eon motor control technology
  • Insulated sloped stainless steel drain pan
  • Advanced unit control board with diagnostic LEDs
  • Double O-ring water connections
  • Easy service access
  • Optional domestic water pre-heating
  • Made in the USA
  • 10 year compressor warranty

Dimensions 23.125" H x 61" D x 25.75" W
AHRI Certified Yes
ASHRAE Compliant No
Base Warranty
5 year limited parts warranty
Blower Motor Hp
Blower Motor Type
Axial Flux (No Shaft) BLA
Color Gray
Color Family
Compressor Motor Type
Contains Aerosol
Contains Chemicals
Contains Compressed Gas
Contains Electronics Yes
Contains Electronics 57000
COP 47 4.0-4.97
COP 47 Part Load 4.5-5.29
EER 19.4-25.8
EER Part Load 26.1-32.8
Energy Star Certified Yes
Energy Star Compliant Yes
ETL Certified No
ETL Listed Yes
Filter Size 20x25 & 20x22
Filter Type Replaceable
Freight Class 70
Has Batteries No
Heating Capacity 57000
LEED Certified No
Max Coverage Area 2500
Max Fuse Breaker 64(W/O Desuperh
Min Circuit Ampacity 38.6
Net Weight 380
Phase 1
Proposition 65 Warning Yes
Refrigerant Type R-410A
Registered Warranty 10 year registered parts limited warranty & 10 year compressor warranty
Restricted States No
Stage Two-Stage
Tonnage 5
UL Listed No
UL Reconized No
Voltage 230


Mini Split FAQ

What BTU rating should I choose for my air handler?

  • This depends on the coverage area/room size you are trying to heat/cool
  • An Air Handler's BTU is how powerful the fan is. A higher BTU rating will be able to heat/cool a larger area
Air Handler BTU Coverage Area/Room Size (Sq Ft.)*
Up to 375 Sq. ft
12K BTU Up to 500 Sq. ft
18K BTU Up to 750 Sq. ft
24k BTU Up to 1000 Sq. ft
36k BTU  Up to 1500 Sq. ft

*Ceiling height, insulation, and local climate may impact the coverage area. For example, an uninsulated room will require more power than a well insulated room.

Shipping & Returns

*Shipping Policy

  • Shipping is Free
  • Large appliances ship via Freight Curbside shipment. Meaning the carrier will drop off your item on your property not inside your home. The courier company will call ahead of time to schedule a drop off date
  • For the full details, visit our Shipping Page

Return/Refund Policy
  • 30-Day Return Policy
  • If your order arrives damaged, we will exchange you for a new one. Damage must be reported within 24 hours.
  • For more details, visit our Return Policy Page


Customer Reviews

Based on 24 reviews
Peter K. (Phoenix, AZ)
Pretty Easy Install and Works Great!

Installed my own central HP system. It was a bit of work but nothing beyond a person with basic mechanical and electrical skills. It took me a while because I had to remove the existing electric forced air furnace from a pretty tight place. Some custom sheet metal work and a bit of custom electrical too. Worked perfectly when powered up and I actually like the thermostat provided, although I wish it was clearer how to set up a temperature set-back schedule. Pre-charged refrigerant piping was something new and I liked that too. The best thing is that my electric utility forked out $4,000 and that paid for the unit!

WesD (Chicago, IL)
Installed and working great

Installed with ceiling cassettes... Quiet and keeping us cool so far !

Deborah B. (Memphis, TN)
Heat pump unit

My unit arrived on time and undamaged. It was installed without a problem. I hate the fuse unit didn't come with it. They did UPS it to me so I didn't have to put installation on hold. The unit is very quiet and works well.

Nat R. (Odessa, TX)
4 ton condensing unit

Very good delivery service installed and works like a Should

walter w. (Port Neches, TX)
Old r22 unit, same capacity, worked better in temperature extremes

Product came packaged well, undamaged. Installation was difficult, followed instructions for suction line above coil on bilevel installation with coil above condenser. 108 inside house on startup, 103 ambient. First start, high pressure 500, low pressure 170, supply air temp 66 degrees. Very worried at first, but after house cooed down, everything within parameters. Researched 410a refrigerant, found out it looses efficiency exponentially during temperature extremes. My old r22 unit would supply 54 degree supply air in comparable operating conditions. EPA, government, a/c manufactures all lying to American public
