| Condenser | 33.27"W x 14.29"D x 27.64"H |
| Air Handler | 42.52"W x 8.90"D x 13.19"H |
| Freight Class | 250 |
| Mount Type | Wall |
| Unit Type | Mini-Split |
| SEER | 20 |
| EER | 12.5 |
| HSPF | 10 |
| CFM | 510/382/320 |
| Tonnage | 1.5 |
| Cooling Capacity | 18,000 BTU |
| Heating Capacity | 18,000 BTU |
| Color | White |
| Decibel | 31/37.5/45 dBA |
| Phase | 1 |
| Min Circuit Ampacity | 15 A |
| Max Coverage Area | 750 sq ft |
| Zone Capacity | 1 |
| Refrigerant Type | R-410A |
| Refrigerant Volume | 68.8 oz |
| Air Flow Direction | 4-Way |
| Speed | 4 |
| Min Ambient Heat | 5 Degrees F |
| Electrical Requirements | 208-230V / 60Hz / 20A |
| Line Set Length | 16ft or 25ft |
| Max Lineset Length | 98ft Max |
| Liquid Line Fitting | 3/8 Inches |
| Liquid Line Size | 1/4 Inches |
| Suction Line Fitting | 5/8 Inches |
| Suction Line Size | 1/2 Inches |
| Control Type | LED |
| Condense Fan Motor RPM | 700/750/85 |
| Blower Motor RPM | 700/800/10 |
| Filter Type | Washable |
| Oscillation | Yes |
| Inverter | Yes |
| Overload Protection | Yes |
| Adjustable Thermometer | Yes |
| Modes |
Quiet Mode Fan Only Auto Cool |
| Wifi Compatibility | Yes |
| App Compatibility | Yes |
| Compatible with: |
iOS Android |
| Includes | Remote Control Batteries |
| Certifications | CSA Energy Star AHRI |
| Registered Warranty | 5-year Parts/7-year Compressor/1-year Remote |
| Contains Electronics | Yes |
| Contains Chemicals | Yes |
| Contains Aerosol | Yes |
| Contains Compressed Gas | Yes |
| Restricted States | GU, PR, VI |
Brochure
Installation Manual
Quick Start Guide
Remote Manual
Smart Controller Manual
*Shipping Policy
I ordered a HVAC system and it arrived in a timely manner and with no apparent issues. I thought the system was defective once installed but it was the installers fault who wired it wrong. My only issue would be the fee (30% I believe) to return a defective item within the 30 day return policy. If it is defective the customer shouldn't have to pay a fee to return an item that is not operating as designed. Other than that this is a good company.
Installed my own central HP system. It was a bit of work but nothing beyond a person with basic mechanical and electrical skills. It took me a while because I had to remove the existing electric forced air furnace from a pretty tight place. Some custom sheet metal work and a bit of custom electrical too. Worked perfectly when powered up and I actually like the thermostat provided, although I wish it was clearer how to set up a temperature set-back schedule. Pre-charged refrigerant piping was something new and I liked that too. The best thing is that my electric utility forked out $4,000 and that paid for the unit!
Installed with ceiling cassettes... Quiet and keeping us cool so far !
Very good customer service will be buying from them again
Was easy to install. Directions were easy to follow and unit is working great
